| Category | Specification |
|---|---|
| COGENG Part Number | CG-KOB-YN35V00051F1 |
| OEM Reference | YN35V00051F1 |
| Valve Series | Kobelco Blue Dot |
| Valve Type | Hydraulic Solenoid |
| Pressure Rating | Meets Kobelco Blue Dot Specifications |
| Response Time | < 50ms |
| Voltage Rating | 12V/24V DC System |
| Operating Pressure | Up to 350 Bar |
| Seal Material | NBR (Hydraulic Fluid Compatible) |
| Temperature Range | -30°C to 100°C |
| Quality Validation | 100% Functional Testing |
| Warranty Coverage | 18-Month Limited Warranty |
Parts list
| NO | Number | Name | Qty |
| YN35V00047F1 | HYDRAULIC VALVE Solenoid | AR | |
| 101 | YN35V00047S101 | CASE | 1 |
| 171 | YX35V00002S171 | SCREW M05x0.8x12mm | 16 |
| 171 | YN35V00047S171 | SCREWM05x0.8mm | 16 |
| 601 | YN35V00048F1 | VALVE Solenoid,SEE (HC851) | 3 |
| 602 | YN35V00049F1 | VALVE Solenoid,SEE (HC852) | 1 |
| 701 | YN35V00050F1 | VALVE Solenoid,SEE (HC853) | 3 |
| 702 | YN35V00051F1 | VALVE Solenoid,SEE (HC854) | 1 |
| 901 | NA | NOT SERVICED Name plate | 1 |
Disconnect battery and completely depressurize hydraulic system
Clean mounting surface and connection ports thoroughly
Use specified hydraulic seals and thread compounds
Torque fittings to manufacturer specifications
Bleed air from system after installation
Test valve operation before returning to service
