| Parameter | YN13E01449P3 | YN14E01106P1 |
|---|---|---|
| COGENG Part Number | YN13E01449P3 | YN14E01106P1 |
| OEM Equivalent | Kobelco YN13E01449P3 | Kobelco YN14E01106P1 |
| Product Type | Main Wiring Harness | Main Wiring Harness |
| Application | Complete machine electrical system | Complete machine electrical system |
| Harness Type | Cab + Engine + Chassis | Cab + Engine + Chassis |
| Harness | Generic / Low-Quality Alternative | |
|---|---|---|
| Part Number | YN13E01449P3 YN14E01106P1 |
May claim compatibility but is not guaranteed to match exactly |
| Compatibility | Designed for specific Kobelco models (e.g., SK130, SK140) | Often a universal "will-fit" that may have incorrect connectors or pin-outs |
| Wire Quality | High-temp, thin-wall insulation; high-purity copper for optimal conductivity | Inferior insulation that can crack; lower conductivity leading to voltage drop |
| Connectors | OEM-specified, sealed connectors with corrosion-resistant terminals | Poor-quality connectors that are prone to corrosion and poor contact |
| Durability | Robust construction with OEM-style routing and protection in high-wear areas | Lacks proper conduit and chafe protection, leading to premature failure |
| Reliability | Fully tested for continuity and insulation; provides long-term, stable performance | High risk of internal faults, shorts, and intermittent failures from day one |
| Warranty & Support | Backed by a comprehensive warranty and technical support | Limited or no warranty, with little to no product support |
| NO | Number | Name | Qty |
| 1 | YB14E00018F1 | HARNESS | 1 |
| 2 | 14E01027P1211 | CLIP | 1 |
| 3 | YN13E01375P1 | BOL | 1 |
| 4 | PY01P0104303 | CLIP | 1 |
| 5 | YN14E01106P1 | HARNESS | 1 |
YN13E01449P3 Harness
Application: Main engine control circuit for Tier 3-compliant Kobelco excavators 1.
Critical Connections:
Engine Control Unit (ECU) via CE03 connector (prevents accidental engine start during diagnostics) 1.
Fuel injectors with torque-sensitive terminals (injector wire harness nut: 1.5 ± 0.25 N·m) 1.
Barometric pressure sensors for compression testing.
Environmental Rating: IP67 protection (validated for oil/water exposure during cylinder pressure tests) 1.
YN14E01106P1 Harness
Application: Fuel injection system integration, specifically for hydraulic-driven injectors.
Key Features:
Reinforced shielding around inlet connectors (fuel pipe bushing nut torque: 35±3.5 N·m) 1.
Compatibility with injector clamp tools (C2-type tool required for removal) 1.
Extended wiring for rocker arm assembly sensors (mounting bolt torque: 36±6 N·m) 1.
Q1: Which Komatsu equipment models use the YN13E01449P3 and YN14E01106P1 main wiring harnesses?
A: These premium main wiring harnesses are designed for specific Komatsu excavators, dozers, or wheel loaders requiring OEM part numbers YN13E01449P3 and YN14E01106P1. Please verify compatibility with your machine model and serial number before ordering.
Q2: What is the difference between YN13E01449P3 and YN14E01106P1?
A: These are two different main harness assemblies – typically one may be for the cab/main machine harness and the other for an attachment or auxiliary system. Please confirm your specific application requirements with your machine details.
Q3: Is this an OEM or aftermarket harness?
A: It is an OEM-grade premium replacement harness, manufactured to meet or exceed original Komatsu quality standards for durability, electrical performance, corrosion resistance, and precise fit.
