| Parameter | Specification |
|---|---|
| COGENG Part Number | YN13E01137P4 |
| OEM Equivalent | Kobelco YN13E01137P4 |
| Product Type | External Wire Harness Assembly |
| Application | Chassis, boom, swing, travel, hydraulic systems (external) |
| Harness Type | External machine harness (cab to chassis, undercarriage) |
| Compatible Models | Kobelco SK200-6, Kobelco SK210-6 Excavators |
| Series | Dash 6 (Tier 2 / Stage II) |
Installation decomposition diagram
System Documentation & Removal:
Photograph entire existing harness routing from multiple angles
Label every connector with waterproof tags identifying components
Use appropriate terminal release tools - never pull on wire conductors
Carefully document routing through complex engine compartments
Note clearance from turbocharger, exhaust manifold, and moving components
Pre-Installation Verification:
Conduct point-by-point comparison with original harness
Verify all connector types, keying, and terminal configurations match
Inspect engine connection points for corrosion or damage
Confirm adequate protection from heat sources and sharp edges
Precision Installation Procedure:
Route new harness following exact documented path
Secure all factory mounting clamps and retention points
Connect sensor and component connections first
Engage ECU and main power connections last
Verify all connector locks engage with audible click
Ensure proper slack allowance for engine movement
System Commissioning & Testing:
Reconnect battery terminals (positive first, then negative)
Turn key to ON position (do not start) for 3-minute system initialization
Perform comprehensive diagnostic scan for trouble codes
Start engine and monitor all system parameters
Verify proper communication across all engine systems
Conduct full operational testing under working conditions
This external wire harness is an essential component for the repair and maintenance of Kobelco excavators. It is ideal for:
Repairing machines suffering from broken wires, short circuits, or corroded connectors.
Restoring proper function to external electrical components like sensors and lights.
Performing scheduled maintenance or overhaul where the wiring harness requires replacement.
Ensuring the electrical system's integrity for safe and uninterrupted machine operation.
