| Parameter | Specification |
|---|---|
| COGENG Part Number | SV-KOB-00005F1-GD |
| Replaces OEM Number | YB35V00005F1 |
| Product Type | Hydraulic Solenoid Valve |
| Identification Mark | Green Dot |
| Voltage Rating | 24V DC |
| Maximum Pressure | 350 Bar (5,075 PSI) |
| Flow Capacity | 25 L/min (6.6 GPM) |
| NO | Number | Name | Qty |
| YN35V00039F | SOLENOID VALVE ASSY | ||
| 101 | YN35V00039510 | BODY | 1 |
| 151 | 2436U1165S152 | PLUG | 1 |
| 171 | YX35V00002S171 | SCREW M05x0.8x12mn | 16 |
| 601 | YB35V00005F1 | VALVE SOLENOID | 4 |
| 701 | YT35V00013F1 | VALVE SOLENOID | 3 |
| 702 | YB35V00006F1 | VALVE SOLENOID | 1 |
| 901 | YA35V00001S901 | PLATE NAME | 1 |
Depressurize hydraulic system completely before installation
Disconnect battery and power sources
Clean work area to prevent contamination
Wear appropriate personal protective equipment
System Preparation:
Relieve all hydraulic pressure
Clean valve and connection areas
Disconnect electrical connector
Valve Replacement:
Remove old valve using proper tools
Install new seals lubricated with clean hydraulic oil
Mount new COGENG solenoid valve
Torque fasteners to specification (15-20 Nm)
System Verification:
Reconnect electrical connector
Pressurize system and check for leaks
Test valve operation
Verify proper system functionality
Maintenance Recommendations:
Inspect during routine hydraulic service
Check electrical connections for corrosion
Monitor for oil leaks
Test operation every 1,000 service hours
Replace as part of preventive maintenance schedule
Warranty: 24-month limited warranty
Technical Support: Available through authorized distributors
Packaging: Individual packaging with installation instructions
