Approved FormulaProduct name: John Deere Engine Oil
Part No: TY22076
Model Number:For Lawn & Garden Equipment, Small Engines, Turf Equipment
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name: John Deere
| Parameter | Value / Specification |
|---|---|
| OEM Part Number | TY22076 |
| Viscosity Grade | SAE 10W-30 |
| API Service Classification | SJ / SL / SM / SN (Meets or exceeds) |
| ILSAC Specification | GF-4 / GF-5 (Meets or exceeds) |
| Base Oil Type | High-Quality Mineral / Conventional |
| Viscosity Index | Approx. 150-170 |
| Pour Point | -30°F (-34°C) |
| Flash Point | > 400°F (204°C) |
| TBN (Total Base Number) | 6.0 - 8.0 mg KOH/g |
| Sulfated Ash Content | < 1.0% |
| Density (at 60°F) | Approx. 0.875 g/cm³ |
| Engine Type | 4-Cycle (Four-Stroke) Only |
| Container Size | 1 Quart (946 mL) |
| Operating Temperature Range | -20°F to 100°F (-29°C to 38°C) for optimal performance |
| Maintenance Item | Recommendation |
|---|---|
| Oil Change Interval | Every 50 hours of operation or annually (whichever comes first) under normal conditions; change every 25 hours under heavy load, high temperature, or dusty conditions |
| Oil Level Check | Inspect before each use. Maintain oil level between the "Full" and "Add" marks on dipstick with engine on level ground and cool |
| Viscosity Selection | SAE 10W-30 recommended for most operating temperatures; suitable for temperatures from 20°F to 100°F (-7°C to 38°C) |
| Filter Replacement | Replace oil filter (if equipped) at every oil change to ensure maximum contaminant removal and oil flow |
| Storage Preparation | Change oil before long-term storage (over 30 days) to remove acidic contaminants and prevent engine corrosion |
| Oil Disposal | Dispose of used oil responsibly at a certified collection center. Do not dispose with household waste or pour into drains |
| Container Disposal | Recycle empty container after thorough rinsing where recycling facilities exist |
| Break-In Period | For new or rebuilt engines, follow manufacturer's break-in procedures; typically first oil change at 5-10 hours of operation |
| Extreme Conditions | For continuous operation in temperatures below 20°F (-7°C), consider SAE 5W-30; for consistent temperatures above 100°F (38°C), SAE 30 may be suitable |
| Safety Category | Precaution / Instruction |
|---|---|
| Personal Protection | Wear chemical-resistant gloves (nitrile recommended) and safety glasses when handling oil to prevent skin and eye contact |
| Skin Contact | Wash thoroughly with soap and water after contact. Do not use solvents or abrasive cleaners. Prolonged or repeated contact may cause skin irritation or dermatitis |
| Eye Contact | Flush eyes immediately with plenty of clean water for at least 15 minutes. Remove contact lenses if present. Seek medical attention if irritation persists |
| Inhalation | Use in well-ventilated area. Avoid prolonged breathing of vapors or mists. If symptoms such as dizziness or headache occur, move to fresh air |
| Ingestion | If swallowed, do not induce vomiting. Seek immediate medical attention. Have container or label available for medical personnel |
| Hot Surfaces | Allow engine to cool for at least 15 minutes before draining oil to prevent burns from hot surfaces and hot oil |
| Spill Management | Absorb spills with inert material (sand, sawdust, absorbent pads, clay). Prevent entry into drains, sewers, or water bodies. Report large spills to environmental authorities as required |
| Storage Conditions | Store in original container in a cool, dry, well-ventilated area away from direct sunlight, sparks, open flames, and sources of ignition |
| Container Disposal | Do not reuse empty containers. Rinse thoroughly and dispose of in accordance with local, state, and federal regulations |
| Environmental Hazard | Oil is toxic to aquatic life and may cause long-term adverse effects in waterways. Do not dispose of in drains, soil, or natural waterways. Used oil is classified as hazardous waste; dispose of properly |
| Fire Hazard | Not classified as flammable, but will burn. Keep away from open flames and high heat sources. Use Class B fire extinguisher (foam, CO₂, dry chemical) for fires |
| First Aid Information | Keep Safety Data Sheet (SDS) available in work area. Seek medical attention for any significant exposure or if symptoms develop |
| Application | Compatible Equipment |
|---|---|
| John Deere Lawn Tractors | D Series, E Series, S Series, X Series (4-cycle models) |
| John Deere Zero-Turn Mowers | Z300, Z500, Z700, Z900 Series |
| John Deere Walk-Behind Mowers | All 4-cycle commercial and residential models |
| John Deere Compact Utility Tractors | 1 Series, 2 Series, 3 Series (gasoline models) |
| John Deere Gators | All gasoline 4-cycle Utility Vehicles |
| Other Brand Equipment | Most 4-cycle small engines from Briggs & Stratton, Kawasaki, Kohler, Honda, and Tecumseh requiring SAE 10W-30 |
| Engine Compatibility | 4-Cycle (Four-Stroke) gasoline engines only — NOT for use in 2-cycle engines |
| Not Recommended For | Diesel engines, 2-cycle (two-stroke) engines, or vehicles requiring higher API ratings (e.g., CK-4, FA-4) |
Quality Assurance:
COGENG ensures that all Turf-Gard engine oil products meet rigorous quality standards, including precision formulation, viscosity stability testing, and contamination control. Each batch is manufactured to maintain consistent performance and reliable engine protection.
Maintenance Best Practices:
Regular Inspections: Check oil level before each use to prevent low-oil operation
Timely Replacement: Follow manufacturer-recommended oil change intervals to maintain engine warranty and performance
Filter Maintenance: Always replace oil filters simultaneously with oil changes for maximum contaminant removal
Record Keeping: Maintain service records to track oil changes and anticipate maintenance needs
Q1: Is TY22076 the same oil as TY26671 just in a bigger jug?
A: Yes. Both are John Deere Turf-Gard SAE 10W-30 meeting specification JDM J20C. The TY22076 is simply the 1 Gallon packaging SKU, while TY26671 is the 1 Quart packaging SKU. The fluid inside the bottle is chemically identical.
Q2: Can I store an opened gallon jug of TY22076 in my cold shed over winter?
A: Yes, but with a caveat. The Pour Point is -33°C, so it will not freeze solid. However, below 0°F (-18°C), the oil will become extremely viscous (thick like honey) .
Recommendation: Before using a jug stored in freezing temperatures, bring it indoors for 24 hours or place the jug in a bucket of warm water (not boiling) for 15 minutes. Pouring cold 10W-30 into a snowblower engine in -10°F weather can starve the oil pump or prevent proper splash lubrication on startup.
Q3: Why does the label say "Turf-Gard" but also says it's for 4-Cycle Engines? Can I use it in my 2-Cycle trimmer?
A: NO.
TY22076 Turf-Gard: Crankcase oil for 4-Cycle engines (separate oil sump).
2-Cycle Engines: Require Air-Cooled 2-Cycle Oil to be mixed with gasoline (e.g., John Deere TY25102 ).
Consequence: Pouring TY22076 into a 2-cycle gas mix will foul the spark plug instantly, produce heavy white smoke, and cause carbon seizure of the piston rings.
Q4: Does COGENG selling this mean it is aftermarket oil in a John Deere bottle?
A: No. COGENG acts as a Redistributor / Parts Supplier. The product you receive under part number TY22076 is Genuine John Deere Fluid manufactured by a licensed John Deere blender. The bottle will feature the green/yellow John Deere logo and the exact TY22076 part number molded into the jug or printed on the label. It is warranty-approved for John Deere equipment.
