Product name: John Deere Engine Oil
Part No: TY22029
Model Number:For Lawn & Garden Equipment, Small Engines, Turf Equipment
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name: John Deere
| Parameter | Value / Specification |
|---|---|
| Oil Type | SAE 10W-30 |
| Viscosity Grade | 10W-30 |
| API Service Classification | SL / SJ / SH / SG / SF / SE / CC / CD |
| Base Oil | High-Quality Mineral / Conventional |
| Engine Type | 4-Cycle (Four-Stroke) |
| Recommended For | Lawn & Garden Equipment, Small Engines, Turf Equipment |
| Key Features | Excellent wear protection, thermal stability, deposit control |
| Packaging | Available in quarts, gallons, and cases |
| Property | Value |
|---|---|
| Viscosity @ 40°C | Approximately 70-80 cSt |
| Viscosity @ 100°C | Approximately 10-12 cSt |
| Viscosity Index | 135-150 |
| Pour Point | -30°F (-34°C) |
| Flash Point | 420°F (215°C) |
| TBN (Total Base Number) | 8-10 mg KOH/g |
| Sulfated Ash | 0.8-1.2% |
| Maintenance Item | Recommendation |
|---|---|
| Oil Change Interval | Every 50 hours of operation or annually (whichever comes first) under normal conditions; more frequent changes (25 hours) under heavy load or dusty conditions |
| Oil Level Check | Inspect before each use. Maintain oil level between the "Full" and "Add" marks on dipstick |
| Viscosity Selection | SAE 10W-30 recommended for most operating temperatures; suitable for temperatures from 20°F to 100°F (-7°C to 38°C) |
| Filter Replacement | Replace oil filter (if equipped) at every oil change to ensure maximum contaminant removal |
| Storage Preparation | Change oil before long-term storage to remove acidic contaminants and prevent engine corrosion |
| Oil Disposal | Dispose of used oil responsibly at a certified collection center. Do not dispose with household waste |
| Bottle Disposal | Recycle empty container after thorough rinsing where facilities exist |
| Break-In Period | For new or rebuilt engines, follow manufacturer's break-in procedures; typically first oil change at 5-10 hours of operation |
| Safety Category | Precaution / Instruction |
|---|---|
| Personal Protection | Wear chemical-resistant gloves (nitrile recommended) and safety glasses when handling oil to prevent skin and eye contact |
| Skin Contact | Wash thoroughly with soap and water after contact. Do not use solvents or abrasive cleaners. Prolonged contact may cause skin irritation |
| Eye Contact | Flush eyes immediately with plenty of clean water for at least 15 minutes. Seek medical attention if irritation persists |
| Inhalation | Use in well-ventilated area. Avoid prolonged breathing of vapors or mists |
| Ingestion | If swallowed, do not induce vomiting. Seek immediate medical attention |
| Hot Surfaces | Allow engine to cool before draining oil to prevent burns from hot surfaces and oil |
| Spill Management | Absorb spills with inert material (sand, sawdust, absorbent pads). Prevent entry into drains, sewers, or water bodies |
| Storage Conditions | Store in original container in a cool, dry, well-ventilated area away from direct sunlight, sparks, and open flames |
| Container Disposal | Do not reuse empty containers. Rinse thoroughly and dispose of in accordance with local regulations |
| Environmental Hazard | Oil is toxic to aquatic life. Do not dispose of in drains, soil, or natural waterways. Used oil is a hazardous waste; dispose of properly |
| First Aid | Keep Safety Data Sheet (SDS) available in work area. Seek medical attention for any significant exposure or if symptoms develop |
| Application | Compatible Equipment |
|---|---|
| John Deere Lawn Tractors | D Series, E Series, S Series, X Series |
| John Deere Zero-Turn Mowers | Z300, Z500, Z700, Z900 Series |
| John Deere Walk-Behind Mowers | All 4-cycle models |
| John Deere Compact Utility Tractors | 1 Series, 2 Series, 3 Series (gasoline models) |
| Other Brand Equipment | Most 4-cycle small engines from Briggs & Stratton, Kawasaki, Kohler, Honda requiring SAE 10W-30 |
| Engine Compatibility | 4-Cycle (Four-Stroke) gasoline engines only — NOT for use in 2-cycle engines |
WARNING: Ergonomic & Slipping Hazards with Bulk Container
Lifting Hazard: The TY22029 2.5-gallon container weighs over 20 lbs (9 kg) . Use proper lifting technique (bend knees, keep back straight). Do not attempt to pour directly from this heavy jug into a small engine fill tube without a pump.
Slipping Hazard: Bulk jugs are prone to "glugging" (uneven air intake) during pouring, causing sudden surges of oil. This can easily overflow a small engine crankcase. Mandatory Tool: Use a Fluid Transfer Pump (Hand Pump) or John Deere TY26514 Spout .
Storage Stability: Once the foil seal is broken, the oil in a partially used TY22029 jug will absorb moisture from humid air over time. If storing for >6 months, seal tightly and store in a dry, temperature-stable location.
