| COGENG Part Number | Replaces OEM Number | Primary Application | Key Features |
|---|---|---|---|
| CG-WH-KOB-13202 | LQ13E01202P1 | Travel Motor & Sensor Harness | IP67 connectors, abrasion-resistant sleeving |
| CG-WH-KOB-13209 | LQ13E01209P1 | Swing System Harness | High-flex conductors, vibration-resistant mounts |
| CG-WH-KOB-13251 | LQ13E01251P1 | Hydraulic Control Harness | Shielded sensor circuits, high-temp protection |
Temperature Rating: -40°C to +125°C
Wire Construction: GPT primary wire with XLPE cross-linked insulation
Connector Types: Sumitomo, JST, and Yazaki OEM equivalents
Environmental Protection: IP67 rated connectors, corrosion-resistant terminals
Quality Standards: ISO 9001:2015 certified manufacturing
Testing Protocol: 100% continuity and hi-pot testing
Compatibility Notes:
Verified for Kobelco SK130-7, SK140-7, and similar 7-Series models
Includes all necessary connectors, seals, and mounting hardware
Matches OEM wire colors, gauges, and circuit configurations exactly
| NO | Number | Name | Qty |
| 1 | B13E00013F1 | Hamess Assembly | 1 |
| 2 | FYD1F01043D8 | CLIP | 20 |
| 3 | YN13E01375P1 | CLIP | 3 |
| 5 | ZW26X08000 | WASHER | 1 |
| 6 | ZN18C08007 | NUT M08x1.25mm | 1 |
| 7 | LQ13E01202P1 | Wiring Harness | 1 |
| LQ13E01209P1 | Wiring Harness | 1 | |
| LQ13E01266P1 | Wiring Harness | 1 | |
| LQ13E012151P1 | Wiring Harness | 1 | |
| 8 | LE13E01063P1 | CABLE | 1 |
| 9 | ZWl6P08000 | WASHER | 1 |
| 10 | ZS18C08016 | SCREWM | 1 |
| 12 | LQ13E01233P1 | GASKET | 1 |
Q: What Kobelco models use the LQ13E01202P1, LQ13E01209P1, and LQ13E01251P1 wiring harness set?
A: The COGENG OEM-compatible wiring harness set is a direct replacement for Kobelco part numbers LQ13E01202P1, LQ13E01209P1, and LQ13E01251P1, designed for specific Kobelco excavator models where these harness part numbers are specified. These three harnesses typically represent different sections of the machine's complete electrical system. Always verify each part number against your machine's parts manual or original harness tags to confirm exact compatibility before ordering.
Q: What are the symptoms of a failing wiring harness on a Kobelco excavator?
A: Common symptoms include intermittent electrical faults, multiple warning lights illuminated on the monitor, unresponsive hydraulic or engine controls, erratic gauge or sensor readings, CAN bus communication errors, specific functions not responding, or unexpected machine shutdowns. Kobelco excavators rely on clean electrical signals for reliable operation, and harness degradation from heat, vibration, and moisture ingress is a frequent source of electrical problems.
Q: What is the difference between the LQ13E01202P1, LQ13E01209P1, and LQ13E01251P1 harnesses?
A: In a three-harness set, each part number typically represents a different harness section. Common configurations include one serving as the main chassis or cab harness, another as the engine harness, and the third as a sub-harness for specific systems such as the monitor, sensor, or pump control circuits. Each harness handles distinct circuits and connectors, and all three work together to form the machine's complete electrical system.
