Decompose pictures
| Reference Number | Part Name | Description & Function |
|---|---|---|
| 1 | Main Multi-Pin Connector Block | Heavy-duty sealed connector housing with multiple terminal slots. Serves as the primary interface to the machine's ECU or main chassis harness. |
| 2 | Solenoid / Sensor Connectors | Individual branch-end connectors (DIN 43650 or similar). Attach directly to solenoid valves, sensors, or actuators on the equipment. |
| 3 | Protective Wire Loom (Conduit) | Flexible, abrasion-resistant corrugated tubing that encases and shields the internal wiring from heat, oil, moisture, and mechanical damage. |
| 4 | Copper Conductor Wires | Color-coded, multi-strand copper core wires that carry 24V DC power and control signals throughout the harness assembly. |
| 5 | Rubber Seals & Grommets | Molded rubber sealing elements integrated into each connector body. Provide IP-rated protection against water, dust, and vibration ingress. |
| 6 | Crimped Terminal Pins & Sockets | Precision brass or tin-plated terminals with positive locking tabs. Ensure secure, low-resistance electrical continuity at every connection point. |
| 7 | Branch Splice Junctions | Factory-sealed nodes where the main harness trunk divides into individual circuit legs for routing to different components. |
| 8 | Frame Mounting Clips & Brackets | Integrated plastic or spring-steel clips that anchor the harness securely to the machine's frame along the designated OEM routing path. |
Parts list
| Item | OEM Reference No. | COGENG Part No. | Description | Qty |
|---|---|---|---|---|
| 1 | GY22441 | CG-GY22441 | Wiring Harness Complete Assembly — Pre-terminated, Plug-and-Play | 1 |
| 2 | — | CG-CONN-SET-GY22441 | Replacement Connector Kit (Main Block + Branch Connectors with Terminals) | 1 Set |
| 3 | — | CG-LOOM-12MM | Replacement Protective Wire Loom / Conduit (Per Meter, Split Type) | As Required |
| 4 | — | CG-TERMINAL-KIT-JD | Assorted Terminal Pin & Socket Kit with Rubber Wire Seals | 1 Set |
| 5 | — | CG-CLIP-FRAME-SET | Frame Mounting Clip & Bracket Set for D-Series Routing | 1 Set |
| Brand | Part Number |
|---|---|
| COGENG | GY22441 |
| John Deere | GY22441 |
| Interchange | GY22442, GY22443, GY22444, MIA12577 |
| Model | Deck Size | Engine | Series | Application |
|---|---|---|---|---|
| D140 | 48-inch | 22 HP V-Twin | D100 Series | Main wire harness |
| D155 | 48-inch | 24 HP V-Twin | D100 Series | Main wire harness |
| D160 | 48-inch | 25 HP V-Twin | D100 Series | Main wire harness |
| D170 | 54-inch | 25 HP V-Twin | D100 Series | Main wire harness |
| Model | Electric PTO | Electric Lift | Headlights | Tail Lights |
|---|---|---|---|---|
| D140 | ✓ | Optional | ✓ | ✓ |
| D155 | ✓ | Optional | ✓ | ✓ |
| D160 | ✓ | Optional | ✓ | ✓ |
| D170 | ✓ | Optional | ✓ | ✓ |
Note: The GY22441 harness supports all four models. Verify compatibility with your equipment model and serial number before ordering. Contact COGENG with your machine details for exact application verification.
| Parameter | Specification |
|---|---|
| System Voltage | 12V DC (John Deere standard) |
| Current Capacity | Up to 30A (main power circuits) |
| Wire Gauge Range | 18AWG - 20AWG (signal) / 14AWG - 16AWG (power) |
| Insulation Resistance | ≥100MΩ @ 500V DC |
| Dielectric Strength | 500V AC/60s No Breakdown |
| Voltage Drop | <0.5V @ rated load |
| Temperature Rating | -40°C to +105°C |
| Component | Material Specification |
|---|---|
| Conductor | High-purity tinned copper (99.9%) |
| Wire Insulation | Heat-resistant PVC / Cross-linked polyethylene |
| Connector Housings | OEM-grade Nylon 66 / PBT (UL94 V-0) |
| Terminals | Tin-plated brass |
| Protective Sleeving | Corrugated conduit / PVC tubing |
| Identification | Color-coded wires (John Deere standard) |
| Parameter | Rating |
|---|---|
| Temperature Range | -40°C to +105°C |
| Ingress Protection | IP54 (IP65 on key connectors) |
| Vibration Resistance | 5G @ 50-500Hz |
| UV Resistance | Designed for outdoor use |
| Chemical Resistance | Resists oil, fuel, common lawn chemicals |
| Circuit Group | Components | Wire Color (Typical) |
|---|---|---|
| Main Power | Battery positive, alternator, starter | Red / Black |
| Ignition System | Ignition switch, starter solenoid, spark | Yellow / Black |
| Safety Interlock | Seat switch, PTO switch, brake switch, reverse switch | Green / White |
| PTO Clutch | Electric PTO clutch engagement | Purple / Blue |
| Lighting | Headlights, tail lights | Brown / Black |
| Electric Lift | Attachment lift/lower (if equipped) | Red / White |
| Charging System | Stator to regulator/rectifier | White / Yellow |
| Hour Meter | Operating hour counter | Black / White |
| Fuel System | Fuel shut-off solenoid | Orange / Black |
| Feature | Supported | Notes |
|---|---|---|
| Electric PTO | ✓ | Standard |
| Electric Lift | Optional | Harness includes provisions |
| Headlights | ✓ | Standard |
| Tail Lights | ✓ | Standard |
| Hour Meter | ✓ | Standard |
| Feature | Supported | Notes |
|---|---|---|
| Electric PTO | ✓ | Standard |
| Electric Lift | ✓ | Standard on D170, optional on D160 |
| Headlights | ✓ | Standard |
| Tail Lights | ✓ | Standard |
| Hour Meter | ✓ | Standard |
| 54-inch Deck | ✓ | D170 only (harness compatible) |
Q: What John Deere models use the GY22441 wiring harness?
A: The COGENG GY22441 wiring harness is a direct OEM replacement specifically designed for John Deere D140, D155, D160, and D170 lawn tractor and garden tractor models. Always verify this part number against your machine's parts manual or the original harness tag to confirm exact compatibility before ordering.
Q: What are the symptoms of a failing wiring harness on a John Deere D Series lawn tractor?
A: Common symptoms include intermittent electrical faults, the engine failing to crank or start, unresponsive PTO (blade engagement), safety switches not functioning correctly, blown fuses, erratic or non-functional instrument panel, or the battery failing to charge properly. Harness degradation on lawn tractors is often caused by vibration, moisture ingress, rodent damage, or physical wear from contact with moving parts.
Q: What material construction is used for this wiring harness?
A: The COGENG GY22441 wiring harness is constructed with quality wiring materials and connector components. The harness incorporates durable connector bodies with appropriate strain relief, and the assembly is designed to match the OEM routing and connection points for John Deere D140, D155, D160, and D170 models.
Q: Is this harness a direct plug-and-play replacement?
A: Yes, the COGENG GY22441 harness is manufactured to exact OEM specifications for connector types, pin assignments, wire gauge, and routing length. It is a direct plug-and-play replacement requiring no wire splicing, soldering, or modifications when installed on compatible John Deere D140, D155, D160, or D170 lawn tractors.
