Product name: Komatsu Fuel Injector
Part No: 6251-11-3100 095000-6070
Model Number:For PC400, PC450, WA500, D375A.
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
| Parameter | Specification |
|---|---|
| COGENG Part Number | 6251-11-3100 |
| DENSO Cross Number | 095000-6070 |
| OEM Equivalent | Komatsu 6251-11-3100 |
| Engine Compatibility | Komatsu 6D125 Series |
| Product Type | Electronic Unit Injector (EUI) / Common Rail Injector |
| Interchange Numbers | 6251-11-3100, 095000-6070, 095000-6071 |
| Parameter | Specification |
|---|---|
| Actuation Type | Solenoid Operated Electronic Control |
| Coil Resistance | 0.85 - 1.15 Ω @ 20°C |
| Peak Current | 24A ± 2A |
| Hold Current | 11A ± 1A |
| Inductance | 1.2 - 1.6 mH |
| Response Time | < 0.4 ms |
| Parameter | Specification |
|---|---|
| Injection Type | High-Pressure Common Rail Direct Injection |
| Maximum Rail Pressure | 1,800 bar (26,100 psi) |
| Nozzle Configuration | 6 holes × 0.165mm |
| Spray Angle | 150 degrees |
| Static Flow Rate | 620 cc/min @ 100 bar |
| Dynamic Flow Tolerance | ±3% |
| Injection Timing | ECU Controlled Variable |
| Parameter | Specification |
|---|---|
| Overall Length | 198 mm |
| Body Diameter | 24 mm |
| Mounting Thread | M16 × 1.5 |
| Clamp Bolt Torque | 68 ± 5 Nm |
| High-Pressure Inlet | M14 × 1.5 |
| Leak Off Connection | 8mm Push-On Type |
| Weight (Each) | 0.82 kg |
| Component | Material Specification |
|---|---|
| Injector Body | Case-Hardened Nickel-Chrome-Moly Steel |
| Nozzle Needle | High-Speed Tool Steel (HSS) with DLC coating |
| Solenoid Coil | High-Temperature Class H Copper |
| Plunger Assembly | Ceramic-Coated Stainless Steel |
| Sealing Washer | Annealed Copper (Single Use) |
| O-Rings | Viton (FKM) -40°C to +200°C |
| Filter Screen | Stainless Steel 20 micron |
| Equipment Model | Application | Engine |
|---|---|---|
| PC400-6 | Hydraulic Excavator (40-ton) | 6D125 |
| PC400LC-6 | Long Track Excavator | 6D125 |
| PC450-6 | Hydraulic Excavator (45-ton) | 6D125 |
| PC450LC-6 | Long Track Excavator | 6D125 |
| PC400-7 | Hydraulic Excavator (40-ton) | 6D125 |
| PC400LC-7 | Long Track Excavator | 6D125 |
| PC450-7 | Hydraulic Excavator (45-ton) | 6D125 |
| PC450LC-7 | Long Track Excavator | 6D125 |
| WA500-3 | Wheel Loader | 6D125 |
| WA500-5 | Wheel Loader | 6D125 |
| D275A-5 | Bulldozer | 6D125 |
| HD465-5 | Articulated Dump Truck | 6D125 |
| Parameter | 6D125 Engine |
|---|---|
| Cylinders | 6 in-line |
| Bore × Stroke | 125mm × 150mm |
| Displacement | 11.05 L (11,050 cc) |
| Compression Ratio | 16.5:1 |
| Power Output | 257-320 kW (345-430 HP) |
| Fuel System | Common Rail (DENSO) |
| Emission Standard | Tier 3 / Stage IIIA |
| Brand | Part Number |
|---|---|
| DENSO | 095000-6070 |
| Komatsu | 6251-11-3100 |
| COGENG | 6251-11-3100 |
| Interchange | 095000-6071, 095000-6072 |
| Feature | Benefit |
|---|---|
| DENSO Common Rail Technology | Precise fuel metering, reduced emissions |
| 6-Hole Nozzle with DLC Coating | Superior atomization, wear resistance |
| Variable Injection Timing | Optimized power across RPM range |
| Multi-Stage Injection | Pilot, main, post injection capability |
| Fast Solenoid Response | <0.4ms for precise control |
| Integrated Filter Screen | Prevents internal contamination |
| DLC Coated Needle | Extended service life (10,000+ hours) |
| Test | Procedure |
|---|---|
| Spray Pattern | High-speed camera visualization |
| Flow Rate | 5-point calibration (0,25,50,75,100%) |
| Solenoid Response | Oscilloscope verification |
| Leak Test | High-pressure sealing verification (2,000 bar) |
| Coil Resistance | 100% measurement |
| Dimensional Inspection | CMM verification |
Q: Is the 6251-11-3100 the same as Denso 095000-6070?
A: Yes, the Komatsu 6251-11-3100 fuel injector is manufactured by Denso and carries the Denso part number 095000-6070. This COGENG injector is a direct OEM replacement for both part numbers, designed for the 6D125 engine platform.
Q: What equipment uses the Komatsu 6D125 engine with this injector?
A: The 6D125 engine equipped with the 6251-11-3100 (095000-6070) injector powers a wide range of Komatsu heavy equipment, including PC400-7, PC450-7 excavators, D155A-6 dozers, and WA600-6 wheel loaders. Verify your machine's engine model and injector part number to confirm compatibility.
Q: What are symptoms of a failing 095000-6070 injector on a PC450-7?
A: Common signs include excessive black smoke under load, noticeable loss of engine power, rough idling or engine misfire, increased fuel consumption, and difficulty starting. A faulty injector can also cause fuel dilution in the engine oil, leading to accelerated internal wear.
