The Ultimate Plug-and-Play Solution for CAT 324D, 325D, and 329D Excavators
| Product Name | External / Chassis Wiring Harness |
|---|---|
| Part Number | 366-9320 (also 3669320) |
| Compatible Machines | CAT 324D, 325D, 329D (Standard, L, LN variants) |
| Harness Type | External / Chassis Harness (Frame & Boom/Stick Routing) |
| Material | 100% Copper + PVC/TPE Insulation + Rubber Seals |
| Warranty | 6 Months |
| Stock Status | ✅ In Stock – Ready to Ship |
| Shipping | Fast Shipping – DHL/FedEx/UPS/TNT |
The COGENG 366-9320 (3669320) External / Chassis Harness is a premium-grade OEM replacement wiring assembly specifically designed for the Caterpillar 324D, 325D, and 329D excavators.
This harness is the "as-chassis" external harness – it runs along the machine frame, boom, and stick, connecting the cab to all exterior electrical functions. It is the backbone for:
Chassis Lighting: Frame-mounted work lights (front and rear).
Boom & Stick Lighting: Work lights along the boom and stick.
Rotating Beacon: Safety warning light on the cab roof.
Hydraulic Quick Coupler: Wiring for engaging/disengaging attachments.
Attachment Control: Auxiliary hydraulic solenoid wiring.
Boom & Stick Position Sensors: For machine stability and auto-leveling.
Travel Alarm: Back-up alarm at the rear of the machine.
Camera Systems: Rearview / boom-tip cameras (if equipped).
Note: Do not confuse this with the Engine Harness (342-3063 for C9) or the Cab Interior Harness. The 366-9320 is the harness that runs on the outside of the machine from the cab to the bucket tip.
Why Choose COGENG 366-9320?
OEM Quality: Manufactured to CAT factory specifications (ISO9001 certified).
Plug-and-Play: All connectors pre-terminated – no cutting, splicing, or crimping.
Durable: Resists UV, oil, diesel, moisture, and physical abrasion.
Available Now: In stock for immediate global dispatch.
| Parameter | Specification |
|---|---|
| Part Number | 366-9320 |
| Alternate Number | 3669320 |
| Application | CAT 324D, 325D, 329D |
| Engine Type | CAT C7 / C7.1 / C9 (D-Series) |
| Harness Type | External / Chassis (Frame + Boom + Stick) |
| Connector Type | Deutsch DT (2-pin, 3-pin), AMP, Sure-Seal, CAT proprietary |
| Insulation | UV-resistant PVC + Braided Nylon |
| Wire Gauge | 0.5mm² (signal) to 4.0mm² (lights/power) |
| Operating Temp | -40°C to +125°C |
| Harness Length | ~12 – 16 meters (depending on boom/stick length) |
| Packaging | PP bag + Carton box |
| Component | Quantity | Description |
|---|---|---|
| Main External Trunk | 1 | Runs from cab roof to bucket tip. |
| Cab Roof Branch | 1 | Beacon light, cab roof work lights, mirror heaters. |
| Chassis Branch (Front) | 1 | Front chassis work lights, attachment solenoids. |
| Chassis Branch (Rear) | 1 | Rear work lights, travel alarm, backup camera. |
| Boom Section | 1 | Boom work lights, boom position sensor, coupler solenoid. |
| Stick Section | 1 | Stick work lights, stick position sensor. |
| Bucket / Tip Branch | 1 | Bucket light, end-of-stick auxiliary connectors. |
| Connectors | As required | Deutsch DT, AMP Sure-Seal (pre-attached). |
| Cable Ties & Clips | As required | OEM-style push mounts and heavy-duty zip ties. |
| Protective Sleeving | Full length | Corrugated loom + braided sleeving at pivot points. |
| Rubber Grommets | 4-6 | For bulkhead entry points. |
| Machine Model | Engine | Compatible Harness | Notes |
|---|---|---|---|
| CAT 324D | C7 / C7.1 | 366-9320 | Standard / Long Undercarriage |
| CAT 324D L | C7 / C7.1 | 366-9320 | Long Undercarriage |
| CAT 325D | C7 / C7.1 | 366-9320 | Standard / Long Undercarriage |
| CAT 325D L | C7 / C7.1 | 366-9320 | Long Undercarriage |
| CAT 329D | C9 / C9.3 | 366-9320 | Standard / Long Undercarriage |
| CAT 329D L | C9 / C9.3 | 366-9320 | Long Undercarriage |
| CAT 320D | C6.6 | Not compatible | Smaller frame – different harness |
| CAT 330D | C9 | Not compatible | Larger frame – different harness |
| CAT 336D | C9 | Not compatible | *Uses 342-3063 Main Harness* |
⚠️ Important: The 366-9320 fits 324D, 325D, and 329D across the D-Series platform. Always verify your machine's Serial Number for confirmation.
✅ Direct OEM replacement for:
CAT Part Number: 366-9320
CAT Part Number: 3669320 (no dash)
✅ Designed For:
CAT 324D (Standard and L)
CAT 325D (Standard, L, LN)
CAT 329D (Standard, L)
Machines with standard reach booms and long sticks
✅ Fits the Following Boom/Stick Combinations:
Standard Boom (5.7m – 6.0m) + Standard Stick (2.9m – 3.2m)
Standard Boom (5.7m – 6.0m) + Long Stick (3.7m – 4.2m)
⚠️ Critical Verification Checks:
Machine Serial Number: Please confirm your machine serial number prefix (e.g., GLD for 325D, WKF for 329D).
Boom Length: 366-9320 is for standard/reach booms. For Mass Excavation booms (shorter, thicker), a different harness may be required.
Stick Length: The harness includes extra length for long sticks. If your machine has a short stick, you will have extra slack to secure.
❌ NOT Compatible With:
CAT 320D (smaller frame – uses a different harness).
CAT 330D / 336D (larger frame – different harness length).
CAT 324C / 325C (C-Series – different electrical architecture).
CAT 324E / 325E / 329E (E-Series – different CAN-bus and lighting).
Mass Excavation booms (shorter boom – harness will be too long).
Q1: What is the difference between 366-9320 and 3669320?
A: No difference. They are the same part number – the dash is simply a formatting difference. CAT part numbers can be written with or without dashes.
Q2: What is the difference between this External Harness (366-9320) and the Main Engine Harness (342-3063)?
A:
| Feature | External Harness (366-9320) | Main Engine Harness (342-3063) |
|---|---|---|
| Location | Cab roof, boom, stick, chassis | Engine block |
| Connects to | Lights, sensors, coupler, travel alarm | ECM, injectors, crank/cam sensors, actuators |
| Application | CAT 324D, 325D, 329D | CAT 336D (with C9 engine) |
They are NOT interchangeable.
Q3: Will 366-9320 fit my CAT 324D L?
A: Yes – the 324D L (long undercarriage) uses the same external harness as the standard 324D.
Q4: Will 366-9320 fit my CAT 329D?
A: Yes – the 329D uses the same harness as the 324D and 325D for the D-Series platform.
Q5: My 325D has a Mass Excavation boom. Will this fit?
A: Possibly not. The Mass Excavation boom is shorter, so the harness will have significant extra length. We recommend checking your old harness part number before ordering.
Q6: Is this a genuine CAT part?
A: No. COGENG is an aftermarket manufacturer (ISO9001) . Our parts are built to OEM specifications, offering the same fit and function at a reduced cost.
Q7: Does this harness include the quick coupler wiring?
A: Yes – the harness includes the pre-wired connector for the hydraulic quick coupler solenoid.
Q8: My 329D has a rear camera – does the harness include it?
A: Yes – the rear chassis branch includes a connector for the backup camera (if equipped).
Q9: How do I know if I have the right stick length?
A: Measure the distance from the boom-stick joint pin to the bucket pin. If it's ~3.7m, it's a long stick. If it's ~2.9m, it's a standard stick. The 366-9320 fits both.
Q10: How long does shipping take?
A: Express shipping (DHL/FedEx) takes 3-7 business days worldwide.
Q11: How do I place a trial order?
A: Contact your COGENG distributor. MOQ is 1 piece.
| Parameter | Value |
|---|---|
| Harness Type | External / Chassis (Cab → Boom → Stick → Bucket) |
| Total Length | Approx. 12 – 16 meters |
| Number of Branches | 18 – 22 branches |
| Number of Connectors | 25 – 35 connectors |
| Wire Gauge Range | 0.5mm² (signal) to 4.0mm² (lights/power) |
| Insulation Material | UV-resistant PVC + Braided Nylon |
| Outer Wrap | Black corrugated loom (HDPE) |
| Temperature Rating | -40°C to +125°C |
| Voltage Rating | 24V DC |
| Connector Brands | Deutsch DT (2-pin, 3-pin), AMP Sure-Seal, CAT proprietary |
| Connector Sealing | IP67 (waterproof when mated) |
| ISO Standard | ISO9001:2015 certified facility |
| Country of Origin | China (Guangdong) |
| HS Code | 85443000 |
| Component | Connector Type | Location on Machine |
|---|---|---|
| Rotating Beacon | 2-pin Deutsch | Cab roof |
| Cab Roof Work Lights | 2-pin Sure-Seal | Cab roof (front/rear) |
| Boom Work Lights | 2-pin Sure-Seal | Along boom |
| Stick Work Lights | 2-pin Sure-Seal | Along stick |
| Bucket Work Light | 2-pin Sure-Seal | Bucket linkage area |
| Hydraulic Quick Coupler | 2-pin Deutsch | Boom foot area |
| Boom Position Sensor | 3-pin Deutsch | Boom foot |
| Stick Position Sensor | 3-pin Deutsch | Boom-stick joint |
| Travel Alarm (Back-up) | 2-pin Deutsch | Rear chassis |
| Rear Work Lights | 2-pin Sure-Seal | Rear chassis |
| Backup Camera | 4-pin Deutsch | Rear chassis (if equipped) |
To ensure we ship the correct 366-9320 External Harness, please provide:
Machine Model: CAT 324D / 325D / 329D (and variant: L, LN).
Machine Serial Number: (e.g., GLD00123, WKF00123) – This is the most reliable method.
Boom Type: Standard Reach / Long Reach / Mass Excavation.
Stick Length: (e.g., 2.9m, 3.2m, 3.7m).
Old Part Number: (Check the tag on the old harness – if readable).
✅ In Stock – Ready to Ship.
✅ MOQ 1 piece accepted for trial orders.
*Shipping Details Delivery Return*
Sales Price:
The displayed price is for reference only. Please contact COGENG sales support for the exact price.
Shipping Method:
Sea, land, or air transport; the specific method is determined based on the nature of the shipment.
Estimated Delivery Time:
Based on the dispatch time from the logistics carrier; the displayed arrival time serves as the reference.
Contact information is provided at the bottom of the page.
Merchant Return Policy:
Products shipped are not eligible for return or exchange.
