Document Version: 1.0
Date of Issue: October 26, 2023
Product Category: Hydraulic Components / Excavator Spare Parts
Brand: Catcorp
Manufacturer Reference: Caterpillar OEM Reference
Application: Hydraulic Cylinder Seal Kit
This document serves as the comprehensive technical specification for the hydraulic seal kit identified by part number 121-1577 (also formatted as 1211577), supplied by Catcorp. This part is a critical component within the hydraulic cylinder systems of Caterpillar excavators and wheeled excavators, specifically designed to restore and maintain the performance of hydraulic cylinders used in boom, arm, bucket, and other applications.
The purpose of this document is to provide engineers, mechanics, procurement specialists, and maintenance teams with a complete understanding of the physical specifications, compatibility, installation protocols, and maintenance requirements for this specific seal kit.
The 121-1577 is a precision-engineered Hydraulic Cylinder Seal Kit manufactured by Catcorp as a direct replacement for the Caterpillar OEM part. This kit contains all necessary seals, O-rings, backup rings, and wear rings required to rebuild a hydraulic cylinder, restoring its ability to convert hydraulic pressure into linear mechanical force.
Hydraulic cylinders are the primary actuation components on an excavator, responsible for controlling the boom, arm, bucket, and other attachments. Over time, the seals within these cylinders wear out due to friction, heat, pressure cycling, and contamination, leading to internal and external leaks, loss of power, and reduced efficiency. This seal kit is essential for restoring the cylinder to like-new condition.
The sealing components are manufactured from high-grade materials such as NBR (Nitrile Butadiene Rubber), PTFE (Polytetrafluoroethylene), and polyurethane (PU) to ensure long service life and reliable sealing performance under the demanding conditions of excavator operation.
Key Functional Characteristics:
Complete Sealing Solution: Contains all seals required for a full cylinder rebuild.
High-Pressure Capability: Designed to withstand operating pressures typical of Caterpillar hydraulic systems.
Chemical Resistance: Seals are resistant to hydraulic oil, water, and common contaminants.
Temperature Resistance: Suitable for operating temperatures ranging from -20°C to +100°C.
Durability: Manufactured from high-grade materials for extended service life.
OEM-Compatible: Manufactured to meet or exceed Caterpillar OEM specifications.
Complete Kit: Includes rod seal, buffer seal, dust wiper, piston seal, wear rings, O-rings, and backup rings.
Precision Manufacturing: All seals are manufactured to exacting tolerances for perfect fit.
Material Excellence: Utilizes NBR, PTFE, and PU materials for optimal performance.
Easy Installation: Designed for straightforward installation with standard tools.
OEM Quality: Manufactured to meet or exceed Caterpillar OEM specifications.
Chemical Resistance: Resistant to hydraulic oil, water, and common contaminants.
Temperature Resistance: Suitable for operating temperatures ranging from -20°C to +100°C.
Catcorp Quality: Manufactured under ISO 9001 quality management system.
The following list details the components included in the 121-1577 seal kit. This part number refers to a complete Hydraulic Cylinder Seal Kit. The breakdown below represents the internal structure of the kit.
| Item No. | Part Number | Description | Quantity | Material |
|---|---|---|---|---|
| 1 | 121-1577 | Hydraulic Cylinder Seal Kit | 1 | Various |
| 2 | 121-1577-RS | Rod Seal | 1 | PU / NBR |
| 3 | 121-1577-BS | Buffer Seal | 1 | PU |
| 4 | 121-1577-DW | Dust Wiper Seal | 1 | PU |
| 5 | 121-1577-PS | Piston Seal | 1 | PTFE / NBR |
| 6 | 121-1577-WR1 | Wear Ring (Rod) | 1 | PTFE |
| 7 | 121-1577-WR2 | Wear Ring (Piston) | 2 | PTFE |
| 8 | 121-1577-OR1 | O-Ring (Piston) | 1 | NBR |
| 9 | 121-1577-BR1 | Backup Ring (Piston) | 2 | PTFE |
| 10 | 121-1577-OR2 | O-Ring (Cylinder Head) | 1 | NBR |
| 11 | 121-1577-BR2 | Backup Ring (Cylinder Head) | 1 | PTFE |
| 12 | 121-1577-OR3 | O-Ring (Cylinder Tube) | 1 | NBR |
| 13 | 121-1577-BR3 | Backup Ring (Cylinder Tube) | 1 | PTFE |
| 14 | 121-1577-PN | Piston Nut Seal | 1 | NBR |
| 15 | 121-1577-CS | Cushion Seal | 1 | NBR |
| 16 | 121-1577-CV | Check Valve Seal | 1 | NBR |
Note: The specific quantities and part numbers of individual seals may vary slightly based on the specific production batch. Always verify with the serial number of your machine.
For maintenance purposes, the following items are recommended to be kept in stock:
Complete Seal Kit: The 121-1577 kit itself.
Hydraulic Oil: ISO VG 46 anti-wear hydraulic oil.
Filter Element: Return filter and suction filter.
Cylinder Rod: In case of rod damage during disassembly.
Cylinder Tube: In case of tube damage during disassembly.
The part number 121-1577 is primarily designed for Caterpillar excavators and wheeled excavators. The following compatibility information is compiled from multiple industry sources.
This part is most commonly found on the following machine models:
Caterpillar 322BLN (Excavator)
Caterpillar 325B (Excavator)
Caterpillar 325BL (Excavator)
Caterpillar 330B (Excavator)
Caterpillar 330BL (Excavator)
Caterpillar M325B (Wheeled Excavator)
Caterpillar W330B (Wheeled Excavator)
When searching for this part, you may encounter the following interchangeable or superseded part numbers. If you cannot find 121-1577, check for these:
121-1578
121-1579
121-1580
121-1581
121-1582
121-1583
121-1584
121-1585
121-1586
Warning: While these numbers are often interchangeable, the specific suffix number usually denotes a specific revision or a different cylinder size. It is crucial to confirm the exact cylinder dimensions before ordering.
Installing a hydraulic cylinder seal kit is a precision operation. Failure to follow these precautions can result in immediate damage to the seals, hydraulic contamination, or personal injury.
Verify Part Number: Ensure the new seal kit matches the old seal kit exactly. Check the dimensions of all seals.
Cleanliness: The hydraulic system is highly sensitive to contamination. Clean the area around the cylinder before disassembly.
Hydraulic Oil: Check the hydraulic tank for debris or metallic particles. If the old cylinder failed catastrophically, the entire hydraulic system must be flushed.
Inspect Mating Parts: Check the cylinder rod for scratches, dents, or excessive wear. Check the cylinder tube for scoring or damage.
Check Pilot Pressure: Verify that the hydraulic pressure supplied to the cylinder is within specification.
Safety First: Ensure the machine is parked on level ground, the engine is off, and the hydraulic system is depressurized before beginning work. Lower all attachments to the ground.
Disassembly: Carefully disassemble the hydraulic cylinder. Use proper tools to avoid damaging the rod or tube.
Cleaning: Thoroughly clean all metal components with a suitable solvent. Dry with compressed air.
Inspection: Inspect all metal components for wear, cracks, or damage. Replace any damaged components.
Seal Installation: Install the new seals in the correct orientation. Use a seal installation tool or a blunt object to avoid damaging the seals.
Lubrication: Lubricate all seals with clean hydraulic oil before assembly.
Assembly: Carefully reassemble the cylinder. Tighten the cylinder head bolts to the specified torque.
This is the most critical step.
Fill Casing: Before connecting the hydraulic hoses, fill the cylinder with clean hydraulic oil.
Air Bleeding:
Start the engine at low idle.
Slowly operate the cylinder in both directions to circulate oil.
Loosen the hose fitting slightly to allow air to escape until oil flows out, then tighten.
Check for Leaks: Inspect all connections for leaks while the system is under pressure.
Final Check: Check the hydraulic oil level in the tank and top up if necessary.
Crush Hazard: The hydraulic cylinder is heavy. Ensure proper lifting equipment is used.
High Pressure: Hydraulic fluid under pressure can penetrate the skin. Relieve pressure before disconnecting lines.
Hot Oil: Allow the system to cool before servicing.
Pinch Points: Keep hands and fingers away from moving parts during installation.
Falling Load Hazard: Always lower attachments to the ground before servicing hydraulic cylinders.
This section provides a detailed breakdown of the excavators compatible with the 121-1577, including specific model years and regional variations.
The 121-1577 seal kit is commonly used in Caterpillar 322B, 325B, and 330B class excavators. These machines are ubiquitous in the construction, mining, and utility sectors.
Caterpillar 322BLN: Produced in the late 1990s to early 2000s. This model is known for its reliability. The 121-1577 is a direct fit for the hydraulic cylinder seal kit.
Caterpillar 325B: A very popular 25-ton class excavator. The 121-1577 is often used as the replacement seal kit for boom, arm, and bucket cylinders.
Caterpillar 325BL: The long-undercarriage version of the 325B. The seal kit is identical.
Caterpillar 330B: A 30-ton class excavator. The 121-1577 is compatible.
Caterpillar 330BL: The long-undercarriage version of the 330B. The seal kit is identical.
Caterpillar M325B: Wheeled excavator based on the 325B. The 121-1577 is compatible.
Caterpillar W330B: Wheeled excavator based on the 330B. The 121-1577 is compatible.
Caterpillar 322C: While the "C" series is a newer generation, some early production units may share components with the "B" series. Always verify by serial number.
Caterpillar 325C: Similar to the 322C, verification is required.
Caterpillar 330C: Verification is required.
Disclaimer: While this part is primarily for Caterpillar, it shares design DNA with other brands. However, seal dimensions may differ. Verification is required.
Komatsu: Some Komatsu excavators (e.g., PC300, PC400) utilize a similar cylinder design. However, the seal dimensions are typically different. Not a direct fit.
Hitachi: Hitachi excavators (e.g., EX300, ZX330) often use a similar hydraulic layout. However, the seal dimensions are often different. Not a direct fit without modification.
Volvo: Volvo EC series (EC360, EC460) typically uses a different seal design and is not compatible with the 121-1577 series.
To ensure compatibility with your specific machine:
Locate the Serial Number: Find the machine's serial number plate (usually in the cab).
Check the Parts Manual: Consult the official Caterpillar parts manual for your specific serial number range.
Visual Inspection: Compare the old seals with the new seals. Check the dimensions (inner diameter, outer diameter, thickness) of all seals.
Measure the Cylinder: Measure the bore diameter and rod diameter of the cylinder to confirm the seal kit size.
Cross-Reference the Part Number: Use the Caterpillar parts catalog to confirm the 121-1577 is the correct part for your machine.
Q1: What is the part number 121-1577 exactly?
A: The 121-1577 is a Hydraulic Cylinder Seal Kit manufactured by Catcorp for Caterpillar 322B, 325B, 330B series excavators and M325B, W330B wheeled excavators. It contains all the seals required to rebuild a hydraulic cylinder.
Q2: Can I replace just the seals without replacing the cylinder?
A: Yes, provided the cylinder rod and tube are in good condition. If the rod is scratched or the tube is scored, the cylinder should be replaced or repaired.
Q3: Why does my hydraulic cylinder leak?
A: Leaking can be caused by:
Worn seals: Replace the seal kit.
Damaged rod: Replace or repair the rod.
Scored tube: Replace or repair the tube.
Contaminated oil: Flush the system and replace the oil.
Q4: What is the warranty period for this part?
A: Standard warranty for these hydraulic components is typically 6 to 12 months, depending on the supplier. However, warranty is void if the unit is disassembled, if the system was not flushed after a previous failure, or if the wrong hydraulic oil was used.
Q5: How do I know if my cylinder is a two-speed or single-speed unit?
A: Hydraulic cylinders are not typically classified as two-speed or single-speed. This classification applies to travel motors. Cylinders are classified by bore diameter, rod diameter, and stroke length.
Q6: Can I use this seal kit on a different brand of excavator?
A: It is not recommended unless you are a qualified hydraulic engineer. While the seals might physically fit, the dimensions may not match the host machine's cylinder, leading to poor performance or failure.
Q7: What type of hydraulic oil should I use?
A: Always use the oil specified by the excavator manufacturer. Typically, this is an ISO VG 46 anti-wear hydraulic oil. Using the wrong viscosity can cause overheating and internal damage.
Q8: Do I need to replace the hydraulic filter after installing a new seal kit?
A: Yes. It is highly recommended to replace the return filter and the suction filter immediately after installation. If the old cylinder failed, the system should be flushed with a flushing fluid, and the filters replaced again after 50 hours of operation.
Q9: What is the typical lead time for this part?
A: Lead times vary. Standard stock items may ship within 24-48 hours. Custom or non-stock items may take 15-30 days for manufacturing or sourcing.
Q10: How do I identify if I have a genuine OEM part or an aftermarket replacement?
A: Genuine OEM parts will have the Caterpillar logo and part number cast or stamped into the metal. Aftermarket parts may have the part number but lack the logo. Catcorp parts are aftermarket replacements manufactured to meet or exceed OEM specifications. Always source from a trusted supplier.
Q11: What is the difference between 121-1577 and other 121-15 numbers?
A: The base number "121-15" indicates the series. The suffix (e.g., -77) indicates the specific revision, configuration, or cylinder size. Always match the complete part number.
Q12: Can I rebuild the hydraulic cylinder instead of replacing it?
A: Yes, hydraulic cylinders are rebuildable. However, it requires specialized tools, a clean environment, and technical expertise. Rebuilding is often more cost-effective than replacement if the core is in good condition.
Q13: How do I know if my hydraulic cylinder is bad?
A: Signs of a bad hydraulic cylinder include:
External leaks: Hydraulic oil around the cylinder.
Internal leaks: Loss of power or speed.
Drifting: The cylinder drifts under load.
Noisy operation: Whining or groaning sounds.
Damaged rod: Scratches, dents, or chrome flaking.
Q14: Can I replace the hydraulic cylinder seal kit myself?
A: Yes, if you have mechanical experience and the proper tools. However, hydraulic systems are complex and can be dangerous. If you are unsure, consult a qualified mechanic.
Q15: What is the difference between a hydraulic cylinder seal kit and a travel motor seal kit?
A: Both are seal kits, but they are designed for different components with different dimensions. The hydraulic cylinder seal kit is specifically sized for the cylinders on the 322B, 325B, 330B, M325B, and W330B.
| Parameter | Specification |
|---|---|
| Part Number | 121-1577 (1211577) |
| Brand | Catcorp |
| Type | Hydraulic Cylinder Seal Kit |
| Series | 121-15 |
| Material | NBR, PTFE, PU |
| Max Pressure | 350 bar (Operating) / 400 bar (Peak) |
| Temperature Range | -20°C to +100°C |
| Oil Type | ISO VG 46 Anti-Wear Hydraulic Oil |
| Weight | Approx. 0.5-1.5 kg (Complete Kit) |
| Application | Boom, Arm, Bucket Cylinder |
| Certification | ISO 9001 |
| Country of Origin | China (Aftermarket) |
| Compatibility | CAT 322BLN, 325B, 325BL, 330B, 330BL, M325B, W330B |
We offer worldwide shipping for all our hydraulic components and spare parts. Our shipping partners include DHL, FedEx, UPS, and EMS to ensure fast and reliable delivery.
Shipping Methods:
Express Shipping: 3-7 business days for urgent orders.
Standard Shipping: 7-15 business days for regular orders.
Economy Shipping: 15-30 business days for bulk orders.
Shipping Costs:
Shipping costs are calculated based on the weight, dimensions, and destination of the package.
For bulk orders, please contact us for a customized shipping quote.
Packaging:
All parts are carefully packaged in protective materials to prevent damage during transit.
Each package is labeled with the part number and quantity for easy identification.
Tracking:
Once your order is shipped, you will receive a tracking number via email.
You can track your order on the carrier's website.
We are committed to ensuring your satisfaction with our products. If you are not completely satisfied with your purchase, we offer a hassle-free return policy.
Return Eligibility:
Returns are accepted within 30 days of delivery.
The item must be unused, in its original packaging, and in the same condition as received.
A valid proof of purchase (order number or receipt) is required.
Non-Returnable Items:
Custom-made or special-order parts.
Parts that have been installed or used.
Parts that have been damaged due to improper installation or handling.
Return Process:
Contact our customer service team to request a return authorization (RA) number.
Pack the item securely in its original packaging.
Ship the item back to the address provided by our customer service team.
Once we receive and inspect the item, we will process your refund or exchange.
Refunds:
Refunds will be processed within 5-7 business days after we receive the returned item.
Refunds will be issued to the original payment method.
Shipping costs are non-refundable unless the return is due to our error.
Exchanges:
If you need to exchange an item, please contact our customer service team.
Exchanges are subject to product availability.
Identify Your Part Number: Use your machine's parts manual or contact us for assistance.
Request a Quote: Send us an email or WhatsApp message with the part number and quantity.
Confirm Your Order: We will provide a proforma invoice for your confirmation.
Make Payment: We accept T/T, Western Union, and other payment methods.
Receive Your Order: We will ship your order promptly and provide tracking information.
Our team of experienced professionals is available to assist you with:
Part identification and compatibility verification.
Technical support and installation guidance.
Shipping and logistics inquiries.
Warranty and return requests.
Business Hours: Monday to Saturday, 9:00 AM – 6:00 PM (GMT+8)
End of Document
Disclaimer: This document is for informational purposes only. The manufacturer reserves the right to change specifications without notice. Always consult the official service manual for your specific machine before performing any repairs. Part numbers and compatibility are based on industry cross-reference data and may vary by region and production year. Catcorp is an aftermarket supplier and is not affiliated with Caterpillar.
*shipping Details Return Sales*
Sales price:
Please contact COGENG sales customer service for specific prices.
Shipping method:
The specific arrangement will be based on the cargo situation.
Estimated delivery time:
It is based on the shipping time of the logistics company, and the arrival time shown shall prevail.
Contact details are at the bottom.
MerchantReturnPolicy:
The products shipped are not returnable or exchangeable.
Contact COGENG
📞 Phone: +86-185-2913-1515 🌐 Instagram
📧 Email: hugo@cogeng.net 🌐 Facebook：Excavator Parts Selection and Replacement Community
💬 WhatsApp +86-185-2913-1515 Facebook: Excavator Wiring Harness
💬 WeChat: +86-185-7865-1106 Facebook: Excavator Wire Harness
🌐 Website: cogeng.net Facebook: Excavator SolenoidValve
Excavator Solenoid Valve Excavator Wiring Harness Excavator Seal Kit
Excavator Pressure Sensor Excavator Revolution Sensor Excavator Water Temp Sensor
Excavator Control Panel Excavator Switch Parts Excavator Motors
Excavator Hydraulic Pump Excavator Other parts Excavator Engine Oil
