| Parameter | Details |
|---|---|
| Product Name | Universal Wiring Harness Set (Multi-Model Range) |
| Brand | COGENG |
| Compatible Brands | Komatsu (and other heavy equipment with matching connectors) |
| Replaces Part Numbers | 8260-06-1510, 20Y-06-31660 |
| Harness Type | Universal / Multi-Application Harness Set |
| Material | 99.9% Pure Copper Conductors + Heat/Oil-Resistant PVC Insulation |
| Standards | Complies with UL 758 & ISO 6722 |
| Temperature Rating | -40°C to +120°C (-40°F to 248°F) |
| Current Capacity | Supports up to 60A circuits |
| Packaging | PP bag inside, carton box outside |
| Payment Terms | Western Union, L/C, T/T, MoneyGram, D/A, D/P |
| MOQ | Acceptable trial order (1 set accepted) |
| Shipping | Air/Sea/Express (FedEx, UPS, DHL, TNT, etc.) |
| Place of Origin | Guangdong, China |
| Certification | ISO9001 |
| Stock Status | ✅ In Stock |
| Warranty | 6 Months |
| Supply Capacity | 500 Sets |
The COGENG Universal Wiring Harness Set is a premium-quality, OEM-compatible electrical wiring assembly designed for Komatsu multi-model excavators. This harness set is engineered to replace 8260-06-1510 and 20Y-06-31660 – two commonly used wiring harness sections in Komatsu excavators.
This universal harness set serves as a power distribution and signal transmission backbone, connecting key electrical components such as:
Fuse/Relay Panels – Power distribution modules
Starter Motor Circuit – Cranking system wiring
Alternator Circuit – Charging system wiring
Chassis Ground Points – Frame and engine grounds
Instrument Panel / Monitor – Signal and power feeds
ECU (Engine Control Unit) – Sensor and actuator power
Manufactured under ISO9001 certified processes, the COGENG universal harness uses 99.9% pure copper conductors (tin-plated for corrosion resistance) and heat/oil-resistant PVC insulation to withstand the harsh environment of heavy construction equipment – constant vibration, temperature extremes (-40°C to +120°C), and exposure to diesel fuel, hydraulic oil, and abrasive debris.
Why Choose COGENG Universal Wiring Harness Set?
Multi-Model Compatibility: Designed to fit a wide range of Komatsu excavators.
OEM Cross-Reference: Direct replacement for 8260-06-1510 and 20Y-06-31660.
High-Quality Materials: 99.9% pure copper for superior conductivity.
Durable Construction: Heat/oil-resistant PVC insulation.
Plug-and-Play: Pre-terminated connectors – no cutting or splicing required.
In Stock: Ready for immediate shipment.
| NO | Number | Name | Qty |
| 1 | 8260-06-1510 | WIRING HARNESS | 1 |
| 2 | 20Y-06-31660 | WIRING HARNESS | 1 |
| 3 | 22U-06-11270 | • FUSIBLE LINK¤ 65A | 1 |
| 4 | 56B-06-11510 | • CONNECTOR | 1 |
| 5 | 56B-06-11530 | • CONNECTOR | 1 |
| 6 | 04434-53412 | CLIP | 1 |
| 7 | 20Y-03-11220 | COLLAR | 1 |
| 8 | 01010-81270 | BOLT | 1 |
| 9 | 01643-31232 | WASHER | 1 |
| 10 | 203-06-61730 | BRACKET | 2 |
| 11 | 01010-81230 | BOLT | 2 |
| 12 | 01643-31232 | WASHER | 2 |
| 13 | 04434-53412 | CLIP | 2 |
| 14 | 01010-81230 | BOLT | 2 |
| 15 | 01643-31232 | WASHER | 2 |
| 16 | 04434-53412 | CLIP | 1 |
| 17 | 01010-81225 | BOLT | 1 |
| 18 | 01643-31232 | WASHER | 1 |
| 19 | 08037-02512 | GROMMET | 1 |
| 20 | 04434-51412 | CLIP | 1 |
| 21 | 01010-81225 | BOLT | 1 |
| 22 | 01643-31232 | WASHER | 1 |
| 23 | 8240-06-1520 | BRACKET | 1 |
| 24 | 01010-81225 | BOLT | 1 |
| 25 | 01643-31232 | WASHER | 1 |
| 26 | 04434-51412 | CLIP | 1 |
| 27 | 01010-81225 | BOLT | 1 |
| 28 | 01643-31232 | WASHER | 1 |
| 29 | 08193-21012 | CLIP | 1 |
| 30 | 01010-81220 | BOLT | 1 |
| 31 | 01643-31232 | WASHER | 1 |
| 32 | 20Y-06-31630 | CABLE | 1 |
| 33 | 08053-01512 | CLIP | 1 |
| 34 | 04434-51012 | CLIP | 1 |
| 35 | 01010-81220 | BOLT | 1 |
| 36 | 01643-31232 | WASHER | 1 |
| 37 | 22U-06-21420 | WIRING HARNESS | 1 |
| 38 | 04434-51012 | CLIP | 1 |
| 39 | 01010-81220 | BOLT | 1 |
| 40 | 01643-31232 | WASHER | 1 |
| 41 | 04434-51010 | CLIP | 1 |
| 42 | 08038-00519 | CAP | 2 |
| Referenced Part Number | Component Type | Typical Application |
|---|---|---|
| 8260-06-1510 | Wiring Harness Section | Komatsu excavators (various models) |
| 20Y-06-31660 | Wiring Harness / Fuse Link | Komatsu PC200-7, PC210-10, PC340-7, etc. |
⚠️ Note: 20Y-06-31660 is sometimes referenced as a fuse/fusible link in some parts catalogs. This COGENG universal set replaces the complete wiring harness section that includes or connects to that fuse link, providing a full assembly solution.
This universal wiring harness set is designed to fit a wide range of Komatsu excavators, including but not limited to:
| Model | Series | Typical Year Range | Application |
|---|---|---|---|
| Komatsu PC200-7 | Dash 7 | 2000–2008 | Standard excavator |
| Komatsu PC210-10 | Dash 10 | 2010–Present | Standard excavator |
| Komatsu PC210LC-10 | Dash 10 | 2010–Present | Long undercarriage |
| Komatsu PC220-7 | Dash 7 | 2000–2008 | Standard excavator |
| Komatsu PC240-7 | Dash 7 | 2001–2008 | Standard excavator |
| Komatsu PC300-7 | Dash 7 | 2000–2008 | Large excavator |
| Komatsu PC340-7 | Dash 7 | 2002–2008 | Large excavator |
| Komatsu PC400-7 | Dash 7 | 2000–2008 | Large excavator |
Additional compatible models (verify before purchase):
| Model | Compatibility |
|---|---|
| Komatsu PC130-7 | ⚠️ Check harness length |
| Komatsu PC160-7 | ⚠️ Check harness length |
| Komatsu PC200-8 | ⚠️ Check connector differences |
| Komatsu PC210-8 | ⚠️ Check connector differences |
| Komatsu PC220-8 | ⚠️ Check connector differences |
| Komatsu PC300-8 | ⚠️ Check connector differences |
⚠️ Important: This is a universal harness set. While it fits multiple models, minor variations in connector type or harness length may exist. Always verify with your machine serial number and old part number.
This universal harness set typically includes the following components:
| Component | Quantity | Description |
|---|---|---|
| Main Power Harness | 1 | Heavy-gauge power distribution cable (battery to fuse panel) |
| Starter/Alternator Harness | 1 | Wiring for starter motor and alternator |
| ECU Power/Communication Harness | 1 | Power and CAN bus wiring to engine ECU |
| Chassis Ground Cables | 2-3 | Frame and engine block ground straps |
| Fuse/Relay Panel Connectors | 2-3 | Pre-terminated connectors for fuse box |
| Connector Pigtails | As required | Pre-terminated Deutsch/AMP connectors |
| Protective Corrugated Loom | Full length | Abrasion and heat resistance |
| Cable Ties & Mounting Clips | 20+ | For securing the harness |
| Rubber Grommets | 4-6 | For bulkhead entry points |
✅ Direct OEM replacement for:
Komatsu part number: 8260-06-1510
Komatsu part number: 20Y-06-31660
✅ Designed For:
Komatsu PC200-7, PC210-10, PC220-7, PC240-7, PC300-7, PC340-7, PC400-7
24V electrical systems (standard for Komatsu excavators)
Diesel engine applications
✅ Material Specifications:
Conductors: 99.9% pure copper (tin-plated)
Insulation: Heat/oil-resistant PVC
Temperature range: -40°C to +120°C
Current capacity: Up to 60A per circuit
⚠️ Before purchasing, please verify:
| Check Item | Why It's Important |
|---|---|
| Your Exact Komatsu Model | Harness length and connector pinouts vary by model |
| Machine Serial Number | Helps confirm specific configuration |
| Old Part Number | Confirm the part you're replacing matches 8260-06-1510 or 20Y-06-31660 |
| Physical Appearance | Take a photo of the old harness and send to supplier |
| Connector Types | Ensure the harness connectors match your machine's wiring |
❌ NOT Universal For:
Komatsu models with different electrical architectures (older Dash 5/6 or newer Dash 8/10 with different connectors)
Machines with aftermarket electrical modifications
12V electrical systems
Non-Komatsu equipment without adapter harnesses
Q1: What is a "universal" wiring harness?
A: A universal harness is designed to fit multiple Komatsu models with similar electrical configurations. However, we strongly recommend verifying fitment with your exact machine model and serial number before ordering.
Q2: Will this harness fit my Komatsu PC200-7?
A: Yes – the PC200-7 is one of the primary compatible models for this harness set.
Q3: Will this harness fit my Komatsu PC210-10?
A: Yes – the PC210-10 is one of the primary compatible models for this harness set.
Q4: What is the difference between 8260-06-1510 and 20Y-06-31660?
A: Both are Komatsu part numbers for wiring harness sections. They may be used in different models or different locations on the same model. This COGENG set replaces both, consolidating them into a single universal solution.
Q5: Is this a genuine Komatsu OEM part?
A: No. COGENG is an aftermarket manufacturer (ISO9001) . This harness is built to OEM specifications as a cost-effective replacement.
Q6: Does this harness come with a wiring diagram / pinout?
A: We strongly recommend requesting a pinout diagram from your supplier before installation. This is essential for ensuring correct connections.
Q7: What is the warranty?
A: COGENG provides a 6-month warranty against manufacturing defects.
Q8: How do I know if this harness fits my machine?
A: Send the following to your supplier:
Your exact Komatsu model and serial number
Photos of the old harness
The old part number (8260-06-1510 or 20Y-06-31660)
Q9: Is this harness in stock for immediate shipping?
A: Yes – COGENG maintains stock of 500+ units. Orders ship within 24–48 hours.
Q10: How long does shipping take?
A:
Express (DHL/FedEx/UPS/TNT): 3–7 business days worldwide.
Air freight: 7–12 days.
Sea freight: 20–40 days.
Q11: How do I place a trial order?
A: Contact your COGENG distributor. MOQ is 1 set.
Ordering Information
To ensure correct fitment, please provide:
Komatsu Model: (e.g., PC200-7, PC210-10, PC340-7)
Machine Serial Number: (critical for verification)
Old Part Number: (8260-06-1510 or 20Y-06-31660)
Photos of Old Harness: (especially connectors and routing)
✅ In Stock – Ready to Ship.
✅ MOQ 1 set accepted for trial orders.
*Shipping Details Delivery Return*
Sales Price:
The displayed price is for reference only. Please contact COGENG sales support for the exact price.
shipping Details Method:
Sea, land, or air transport; the specific method is determined based on the nature of the shipment.
Estimated Delivery Time:
Based on the dispatch time from the logistics carrier; the displayed arrival time serves as the reference.
Contact information is provided at the bottom of the page.
Merchant Return Policy:
Products shipped are not eligible for return or exchange.
