4614911 HITACH Throttle Motor
Product name: HITACH Throttle Motor
Part No: 4614911
Model Number:For EX100-5 EX120 EX135C EX135LC EX180 EX1820CW EX200LC EX200-5 EX210 EX210CW EX230LC EX230LC-5 EX270LC EX330LC ZAXIS130 ZAXIS200 ZAXIS330 ZAXIS450 KP56RM2G-019 KP56RM2G-007
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
| Specification Category |
Technical Specifications |
| Compatible Hitachi EX Models |
EX100-5, EX120, EX135C, EX135LC, EX180, EX1820CW, EX200LC, EX200-5, EX210, EX210CW, EX230LC, EX230LC-5, EX270LC, EX330LC |
| Compatible Hitachi ZAXIS Models |
ZAXIS130, ZAXIS200, ZAXIS330, ZAXIS450 |
| Additional Compatibility |
KP56RM2G-019, KP56RM2G-007 |
| COGENG Part Number |
CG-HIT-UNI-TM-50 |
| Replaces OEM Part Number |
4614911 |
| Product Type |
Advanced Universal Throttle Motor Assembly |
| Motor Technology |
Brushless DC with Smart Drive Electronics |
| Operating Voltage |
12V/24V DC (Auto-configuring) |
| Protection Rating |
IP69K Hermetically Sealed |
| Position Sensing |
Triple-Redundant Hybrid Sensing System |
| Operating Temperature |
-45°C to 135°C |
| Response Time |
<50ms Full Range |
| Duty Cycle |
200% Overload Capability |
| Quality Assurance |
MIL-STD-810H Environmental Testing |
| Warranty |
5,000-Hour Platinum Warranty |
Decompose pictures
Parts list
| NO |
Number |
Name |
Qty |
| 0 |
4614911 |
Throttle Motor |
1 |
| 1 |
19M8954 |
Screw |
3 |
| 2 |
19M8955 |
Lever |
1 |
| 2A |
FYA40004949 |
Lever |
1 |
| 2B |
19M7660 |
Screw |
1 |
| 3 |
8079753 |
Bracket |
1 |
| 4 |
FYA40008896 |
Bracket |
1 |
| 5 |
FYA40008897 |
Screw With Washer |
7 |
| 5 |
19M7662 |
Cap Screw |
7 |
| 5 |
24M7346 |
Washer |
7 |
| 7 |
4602634 |
Bracket |
1 |
| 8 |
4602634 |
Bracket |
1 |
| 10 |
FYA00007395 |
Cable |
1 |
| 11 |
14M7272 |
Nut |
2 |
| 12 |
12M7006 |
Lock Washer |
2 |
| 14 |
4190275 |
Clamp |
2 |
| 15 |
T38377 |
Clamp |
2 |
| 16 |
T38378 |
Screw With Washer |
4 |
| 16 |
19M7402 |
Cap Screw |
4 |
| 16 |
24M7346 |
Washer |
4 |
| 18 |
H77698 |
Tie Band |
2 |
| 19 |
H77698 |
Tie Band |
1 |
Installation decomposition diagram
