22U-06-11790 Komatsu Throttle Motor PC228UU-2 PC228US-2 PC60-7 PC228-3
Product name: Komatsu Throttle Motor
Part No: 22U-06-11790 22U0611790
Model Number:For PC228UU-2 PC228US-2 PC60-7 PC228-3
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
| Specification Category |
Technical Specifications |
| Compatible Applications |
Komatsu Equipment (Compatible with 22U-06-11790 applications) |
| COGENG Part Number |
CG-KOM-TM-31 |
| Replaces OEM Part Number |
22U-06-11790 |
| Product Type |
Electronic Throttle Motor Assembly |
| Operating Voltage |
12V/24V DC |
| Protection Rating |
IP67 Sealed Connectors |
| Position Sensing |
Integrated Position Sensor |
| Operating Temperature |
-30°C to 85°C |
| Quality Assurance |
100% Performance Tested |
| Warranty |
COGENG 12-Month Warranty |
Decompose pictures
Here are some additional details about
The Komatsu Throttle Motor 22U-06-11790 is an essential component in the throttle control system of Komatsu equipment. Here are some additional details about this throttle motor:
Function: The throttle motor is responsible for controlling the engine's throttle valve. It receives signals from the machine's electronic control system and adjusts the throttle valve's position accordingly. This helps regulate the engine's speed and power output.
Compatibility: The 22U-06-11790 Komatsu Throttle Motor is designed for use in various Komatsu equipment models, including excavators, bulldozers, wheel loaders, and other construction machinery. It meets the compatibility requirements for these machines.
OEM Quality: The throttle motor is an original equipment manufacturer (OEM) part, ensuring it meets Komatsu's high standards for quality, performance, and durability. It is designed to fit and function perfectly in Komatsu equipment, providing reliable and long-lasting performance.
Precise Control: The throttle motor offers precise and responsive control over the engine's throttle valve. It ensures smooth and accurate adjustments to the engine's speed, allowing operators to achieve the desired level of power and performance.
Easy Installation: The 22U-06-11790 throttle motor is designed for easy installation, enabling technicians to replace or install it quickly and efficiently. This helps minimize downtime and ensures the equipment's prompt return to operation.
Durability: The throttle motor is built to withstand the demanding conditions of construction and heavy equipment applications. It is engineered with robust materials and components to provide reliable performance even in harsh environments.
Safety and Efficiency: The proper functioning of the throttle motor is crucial for the safe and efficient operation of Komatsu equipment. It helps maintain stable engine speed, which contributes to smooth machine operation and enhances operator control.
Parts list
| NO |
Number |
Name |
Qty |
| 1 |
22U-43-11111 |
BRACKET |
1 |
| 2 |
01010-80845 |
BOLT |
3 |
| 3 |
01643-30823 |
WASHER |
3 |
| 4 |
22U-06-11821 |
BRACKET |
1 |
| 5 |
01010-81230 |
BOLT |
2 |
| 6 |
01643-31232 |
WASHER |
2 |
| 7 |
22U-06-11790 |
Throttle Motor |
1 |
| 8 |
01252-70620 |
BOLT |
3 |
| 9 |
01643-30623 |
WASHER |
3 |
| 10 |
01580-10605 |
NUT |
1 |
| 11 |
01602-20619 |
WASHER |
1 |
| 12 |
08036-00614 |
CLIP |
2 |
| 13 |
01010-81020 |
BOLT |
1 |
| 14 |
01643-31032 |
WASHER |
1 |
| 15 |
22U-06-11574 |
COVER |
1 |
|
22U-06-11573 |
COVER |
1 |
| 16 |
01010-80620 |
BOLT |
2 |
| 17 |
01643-30623 |
WASHER |
2 |
Installation decomposition diagram
-
System Power Down: Disconnect the battery and main power sources before beginning installation
-
Linkage Documentation: Note the position and orientation of throttle linkage before disassembly
-
Proper Connector Handling: Use care when disconnecting electrical connectors to prevent damage
-
Mounting Surface Check: Ensure the mounting surface is clean and free from damage
-
Linkage Verification: Confirm throttle linkage moves freely through its entire range after installation
-
System Calibration: Perform throttle calibration using appropriate diagnostic equipment
-
Operational Testing: Verify proper throttle operation through complete speed range
