22B-43-11141 22B-43-11142 22B-43-11143 Komatsu Throttle Motor
Product name: Komatsu Throttle Motor
Part No: 22B-43-11141 22B-43-11142 22B-43-11143 22B4311141 22B4311142 22B4311143
Model Number:For PC128US-2-EU PC128US-2-N PC228UU-1
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
| Specification Category |
Technical Specifications |
| Compatible Applications |
Komatsu Equipment (Compatible with 22B-43-11141/11142/11143 applications) |
| COGENG Part Number |
CG-KOM-TM-33 |
| Replaces OEM Part Numbers |
22B-43-11141, 22B-43-11142, 22B-43-11143 |
| Product Type |
Electronic Throttle Motor Assembly |
| Operating Voltage |
12V/24V DC (Auto-sensing) |
| Protection Rating |
IP67 Sealed Connectors and Housing |
| Position Sensing |
Non-Contact Hall Effect Sensor |
| Operating Temperature |
-40°C to 105°C |
| Duty Cycle |
100% Continuous Duty Rated |
| Quality Assurance |
100% Performance and Environmental Tested |
| Warranty |
COGENG 18-Month Unlimited Hour Warranty |
Decompose pictures
Parts list
| NO |
Number |
Name |
Qty |
| 1 |
22B-43-11141 |
Throttle Motor |
1 |
|
22B-43-11142 |
Throttle Motor |
1 |
|
22B-43-11143 |
Throttle Motor |
1 |
| 2 |
01023-70625 |
SCREW |
3 |
| 3 |
21W-54-21822 |
BRACKET |
1 |
| 3 |
21W-54-21821 |
BRACKET |
1 |
| 4 |
01023-70616 |
SCREW |
4 |
| 5 |
21W-43-21291 |
JOINT |
1 |
| 5 |
21W-43-21290 |
JOINT |
1 |
| 6 |
21W-43-31140 |
SCREW |
4 |
| 7 |
21W-43-21273 |
SHAFT |
1 |
| 7 |
21W-43-21272 |
SHAFT |
1 |
| 8 |
201-43-72190 |
BOSS |
1 |
| 8 |
21W-43-21283 |
BOSS |
1 |
| 9 |
21W-43-21260 |
BOSS |
1 |
| 10 |
21W-43-21230 |
PLATE |
1 |
| 11 |
21Y-43-17140 |
DIAL |
1 |
| 12 |
21W-43-21241 |
PIN |
1 |
| 13 |
201-43-72180 |
PIN,SPRING |
1 |
| 13 |
04025-00308 |
PIN |
1 |
| 14 |
21W-06-21311 |
LAMP |
1 |
| 15 |
08034-00823 |
BAND |
1 |
Installation decomposition diagram
-
Complete System Power Down: Disconnect all battery and power sources. Wait 15 minutes for system capacitors to discharge completely
-
Linkage Documentation: Photograph and document throttle linkage configuration before disassembly
-
Connector Safety: Use proper technique when disconnecting electrical connectors to prevent damage
-
Mounting Surface Preparation: Clean and inspect mounting surface for damage or corrosion
-
Linkage Freedom Check: Verify throttle linkage moves smoothly through entire range without binding
-
System Calibration: Perform complete throttle calibration using appropriate diagnostic equipment
-
Operational Verification: Test throttle operation through full speed range and verify proper response
