| Specification Category | Detailed Specification |
|---|---|
| COGENG Part Number | CG-CAT-1957226 |
| OEM Reference Number | 195-7226 |
| Compatible Equipment | CAT 330C, 330CFM with C-9 Engine |
| Engine Compatibility | Caterpillar C-9 Engine |
| Wire Insulation Material | High-Temperature Oil-Resistant XLPE |
| Connector Protection Rating | IP66 Rated (Engine Environment) |
| Operating Temperature Range | -40°C to 150°C |
| System Voltage Rating | 24V DC System |
| Quality Verification | 100% Circuit & Sensor Continuity Tested |
| Warranty Protection | 18-Month Limited Warranty |
| NO | Number | Name | Qty |
| Grp | 204-3604 | WIRING GP-ELECTRONIC CONTROL | |
| 1 | 3S-2093 | STRAP-CABLE | 25 |
| 2 | 215-3249 | HARNESS AS-ENGINE | 1 |
| 3 | 195-7226 | HARNESS AS-ENGINE | 1 |
| 3 | 226-0903 | CABLE AS | 1 |
| 4 | 230-6279 | HARNESS AS-ENGINE | 1 |
| 5 | 209-5582 | SWITCH GP-MAGNETIC | 1 |
| 6 | 208-9277 | BOLT-FLANGE HEAD | 2 |
| 7 | 4P-7581 | CLIP | 5 |
| 8 | 4P-8134 | CLIP | 3 |
| 9 | 5P-7970 | NUT | 1 |
| 10 | 6V-4369 | WASHER | 4 |
| 11 | 6V-6317 | BOLT | 3 |
| 12 | 8T-4137 | BOLT | 1 |
| 13 | 8T-0328 | WASHER-HARD | 1 |
| 14 | 7I-2272 | BOLT | 2 |
| 15 | 8T-4205 | WASHER-HARD | 1 |
| 16 | 9M-1974 | WASHER-HARD | 1 |
| 17 | 105-1797 | MOUNT | 5 |
| 18 | 9X-3401 | PIN-CONNECTOR | 12 |
| 19 | 126-1767 | PIN-CONNECTOR | 12 |
| 20 | 191-7823 | RECEPTACLE AS | 1 |
| 21 | 307-8428 | GASKET | 1 |
| 22 | 3S-2093 | STRAP-CABLE | 5 |
| Parameter | Specification |
|---|---|
| System Voltage | 24V DC (C-9 Engine Specific) |
| Max Current Capacity | 60A (Starter & Charging Circuits) |
| Wire Gauge Range | 2AWG - 20AWG (Heavy-Duty Engine Requirements) |
| Insulation Resistance | ≥2500MΩ @ 2000V DC |
| Dielectric Strength | 4500V AC/60s No Breakdown |
Plug-and-Play: Universal Connector System
Diagnostic Integration: CAT ET Compatible
Smart Configuration: Software-Assisted Setup
Installation Time: 2-3 Hours (Professional)
Disconnect battery and engine control module before installation
Follow exact OEM routing around engine components
Secure all mounting points and protective covers
Verify all sensor connectors are fully engaged
Perform engine system diagnostic after installation
