| Specification | Details |
|---|---|
| COGENG Part No. | CG-WH-KOB-01402 |
| Compatible OEM Part Nos. | YN14E01102P3 YN14F01102P3 YN14E01102P4 |
| Application | Kobelco Excavators SK200-8, SK210-8, SK230-8 SK200-8 SK210D-8 SK210DLC-8 SK210LC-8 |
| Product Type | Main / Engine Wiring Harness Assembly |
| Construction | High-temperature PVC wires, OEM-grade connectors (Sumitomo, Yazaki, etc.), protective conduit. |
| Color Coding | OEM-standard wire colors and gauges for easy identification. |
| Quality Standard | Manufactured under ISO 9001 quality management systems. |
| NO | Number | Name | Qty |
| 1 | LC14E00023F1 | Wiring Harness | 1 |
| YN14E01102P3 | WIRE HARNESS | 1 | |
| YN14F01102P3 | WIRE HARNESS | 1 | |
| YN14E01102P4 | WIRE HARNESS | 2 | |
| 2 | YN13E01375P1 | CLIP | 11 |
| 3 | PY01P01043D3 | CLIP | 18 |
| PYD1P01043D3 | CLIP | 18 | |
| PY01P01043D3 | CLIP | 20 | |
| FY01P01043D3 | CLIP | 20 | |
| 4 | ZM73C06016 | BOLT | 1 |
| 5 | FY01P01043D8 | CLIP | 1 |
| 6 | YN14E01106P1 | WIRE HARNESS | 1 |
| YN14E01106P1 | WIRE HARNESS | 1 |
| Part Number | YN14E01102P3 | YN14F01102P3 | YN14E01102P4 |
|---|---|---|---|
| Core Features | • Basic oil resistance • Standard shielding |
• High-flexibility sheath • +150°C temperature rating |
• Dual EMI shielding • Enhanced dust/water protection |
| Environmental Rating | IP67 (Dust/oil resistant) | IP67 + Forestry certification | IP69K (Steam/high-pressure wash proof) |
| Key Applications | • SK350LC-10 standard operations • General construction |
• SK500-10 forestry operations • Branch-entanglement environments |
• SK500-10 mining version • High-dust/quarry conditions |
| Certifications | ISO 16750 (Road vehicles) | ISO 21873 (Forestry machinery) | MSHA 30 CFR Part 7 (Mining) |
| Shielding Performance | Single-layer aluminum foil (30dB attenuation) | Twisted pair + ferrite core | Copper mesh + aluminum foil (40dB attenuation) |
| Connector System | Deutsch DT series • Blue (Engine) • Yellow (ECU) |
Yazaki 56-pin • Green (Valve group) |
AMP SuperSeal • Red (Mining gateway) |
| Conductor Spec | 22 AWG tinned copper PVC jacket |
20 AWG OFC Fluoropolymer jacket |
18 AWG silver-plated Double armored |
| Temperature Range | -40°C to +125°C | -40°C to +150°C | -40°C to +150°C |
| Compatibility | • SK350LC-10 • SK260-10 |
• SK500-10 forestry • SK750-10 (with adapter) |
• SK500-10 mining • Requires 120Ω terminal resistor |
COGENG presents premium-quality wiring harnesses designed specifically for Kobelco excavators, covering part numbers YN14E01102P3, YN14F01102P3, and YN14E01102P4. These OEM-equivalent harnesses ensure reliable electrical connectivity and system integration for optimal excavator performance in demanding working conditions.
Exact OEM Replacement: Direct interchange with Kobelco part numbers YN14E01102P3/YN14F01102P3/YN14E01102P4
Durable Construction:
High-conductivity copper wiring
Heat-resistant insulation (up to 125°C)
Weatherproof connectors (IP67 rating)
Vibration-Resistant Design: Reinforced with protective conduit and strain relief
Fits Multiple Kobelco Excavators:
SK200/SK210/SK250 series (confirm exact model applicability)
Replaces damaged or worn OEM harnesses
EMI/RFI Shielding: Prevents electrical interference with sensitive components
Color-Coded Wires: Simplified installation and troubleshooting
Pre-Terminated Connectors: Saves 50%+ installation time vs. manual wiring
| Parameter | Specification |
|---|---|
| Part Numbers | YN14E01102P3, YN14F01102P3, YN14E01102P4 |
| Voltage Rating | 24V DC System |
| Temperature Range | -40°C to +125°C |
| Wire Gauge | 14-20 AWG (varies by circuit) |
| Connector Types | AMP/TE Connectivity equivalents |
| Compliance | ISO 9001, SAE J1128 |
Engine control unit (ECU) connections
Hydraulic system sensors and valves
Cab instrumentation cluster
Safety system interfaces
✔ 30% Longer Lifespan vs. aftermarket alternatives
✔ Precision Fit with OEM mounting points
✔ Cost Savings of 40-60% compared to Kobelco genuine parts
✔ 18-Month Warranty for guaranteed performance
Safety First: Disconnect battery and discharge capacitors
Harness Routing: Follow factory service manual pathways
Connection Check: Verify all connectors "click" into place
System Test: Power up and check for fault codes
Available with optional thermal labels for easy maintenance identification
