11E9-4603 11E9-46071 11E9-46072 11E9-62010 Hyundai Throttle Motor
Product name: Hyundai Throttle Motor
Part No: 11E9-4603 11E9-46071 11E9-46072 11E9-62010
11E94603 11E946071 11E946072 11E962010
Model Number:For R160LC-3 R290LC-7 R320LC-7 R290LC-3 R290
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
| Specification Category |
Technical Specifications |
| Compatible Applications |
JCB Equipment (Compatible with 25-220804, 25-220990, 459-M2874 applications) |
| COGENG Part Number |
CG-JCB-SV-35 |
| Replaces OEM Part Numbers |
25-220804, 25-220990, 459-M2874 |
| Product Type |
Electro-Hydraulic Solenoid Valve |
| Operating Voltage |
12V/24V DC |
| Maximum Pressure |
350 Bar (5,000 PSI) |
| Fluid Compatibility |
Mineral-based, synthetic, and bio-degradable hydraulic oils |
| Temperature Range |
-40°C to 120°C |
| Protection Rating |
IP67 Sealed Connectors |
| Quality Assurance |
100% Pressure and Performance Tested |
| Warranty |
COGENG 12-Month Warranty |
Decompose pictures
Parts list
| NO |
Number |
Name |
Qty |
| 1 |
11E9-4601 |
Bracket |
1 |
| 2 |
11E9-4605 |
Bracket Wa |
1 |
| 4 |
11E6-4506 |
Cable-Push Pull |
1 |
| 6 |
11E6-4505 |
Lever |
1 |
| 7 |
E111-4504 |
End-Rod |
2 |
|
E111-4504 |
End-Rod |
1 |
| 8 |
S015-060252 |
Bolt-Hex |
2 |
| 9 |
S015-060352 |
Bolt-Hex |
2 |
| 11 |
S017-100502 |
Bolt-Hex |
4 |
| 12 |
S017-100202 |
Bolt-Hex |
3 |
| 13 |
S411-060002 |
Washer-Spring |
4 |
| 15 |
S411-100002 |
Washer-Spnng |
8 |
| 16 |
S201-061002 |
Nut-Hex |
4 |
|
S201-061002 |
Nut-Hex |
2 |
| 17 |
11E9-4604 |
Lever Assy |
1 |
| 18 |
S471-500204 |
Pin-Spring |
1 |
| 19 |
11E9-4603 |
Throttle Motor |
1 |
|
11E9-46071 |
Throttle Motor |
1 |
|
11E9-46072 |
Throttle Motor |
1 |
|
11E9-62010 |
Throttle Motor |
1 |
| 19-1 |
21E9-30010 |
.Potentiometer |
1 |
| 20 |
S017-100402 |
Bolt-Hex |
1 |
| 21 |
S205-101002 |
Nut-Hex |
1 |
| 22 |
11EM-60030 |
End-Rod |
2 |
| 23 |
S205-081002 |
Nut-Hex |
2 |
Installation decomposition diagram
-
System Pressure Relief: Completely relieve all hydraulic system pressure before beginning installation
-
Hydraulic Line Documentation: Mark and photograph all hydraulic line connections for proper reassembly
-
Electrical Connection Safety: Disconnect battery and main power sources before handling electrical connections
-
Port Protection: Immediately cap all open hydraulic ports to prevent contamination
-
Seal Inspection: Verify all seals are properly installed and lubricated before connection
-
System Bleeding: Properly bleed hydraulic system after installation to remove air
-
Operational Testing: Test valve function through complete operational cycle before returning to service
