Product name: Liebherr Wiring Harness
Part No: 11692456
Model Number:For R914 R924 R934 R944 R954
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
| Parameter | Specification |
|---|---|
| COGENG Part Number | 11692456 |
| OEM Equivalent | Liebherr 11692456 |
| Product Type | Digital Camera Wiring Harness |
| Application | Backup / Surround-View Camera System |
| Signal Type | HD video (analog or digital) + power + CAN |
| Connector Type | FAKRA / Deutsch / HSD (High-Speed Data) |
| rt No. | Liebherr 11692456 | Direct OEM Replacement |
| Video Standard | HD-SDI 720p/1080p | SMPTE 292M |
| Impedance | 75Ω ±3% (coaxial) | IEC 61196 |
| Bandwidth | 0-1.5 GHz | IEC 60169 |
| Insertion Loss | < 0.5 dB/m @ 1 GHz | DIN 47235 |
| Shielding Effectiveness | >90 dB @ 1 GHz | IEC 60950 |
| Voltage Rating | 12V DC ±10% | ISO 16750-2 |
| Current Capacity | 2A maximum | DIN 43671 |
| Temperature Rating | -40°C to +105°C (-40°F to +221°F) | ISO 16750-4 |
| Cable Type | RG-179 equivalent | MIL-C-17 |
| Connector System | Liebherr CAM-Lock | Liebherr SPEC-88 |
| Environmental Rating | IP69K | DIN 40050-9 |
| Minimum Bend Radius | 25mm | IEC 61196-1 |
| Circuit Function | Cable Type | Impedance | Connector Type | Purpose |
| Video Signal | Coaxial RG-179 | 75Ω | CAM-Lock Gold | HD video transmission |
| Camera Power | 2-conductor 0.5 mm² | N/A | CAM-Lock Power | 12V DC power supply |
| Reverse Signal | Shielded twisted pair | 100Ω | CAM-Lock Data | Reverse trigger |
| CAN Communication | Shielded twisted pair | 120Ω | CAM-Lock Data | Camera control |
| Ground Reference | 0.5 mm² | N/A | CAM-Lock Ground | Signal ground |
| Model Series | Specific Models | Camera System | Display Compatibility |
| Liebherr R 914 | R 914 Compact Litronic | Liebherr HD-Cam Pro | LCS 7" Display |
| Liebherr R 924 | R 924 Compact Litronic | Liebherr HD-Cam Pro | LCS 10" Display |
| Liebherr R 934 | R 934 Compact Litronic | Liebherr HD-Cam Pro | LCS 10" Display |
| Liebherr R 944 | R 944 Compact Litronic | Liebherr HD-Cam Pro | LCS 12" Display |
| Liebherr R 954 | R 954 Compact Litronic | Liebherr HD-Cam Pro | LCS 12" Display |
Installation decomposition diagram
| Parameter | Minimum | Typical | Maximum |
|---|---|---|---|
| Video Signal Level | 800 mVpp | 1000 mVpp | 1200 mVpp |
| Power Supply Voltage | 11.5V DC | 12.0V DC | 12.5V DC |
| Signal-to-Noise Ratio | >55 dB | >60 dB | N/A |
| Return Loss | >20 dB | >25 dB | N/A |
| DC Resistance | N/A | <0.1Ω/m | <0.15Ω/m |
| Maintenance Activity | Interval | Parameters | Test Equipment |
|---|---|---|---|
| Visual Inspection | 250 hours | Check for physical damage | Visual assessment |
| Connector Check | 500 hours | Verify IP69K seal integrity | CAM-Lock test tool |
| Signal Quality Test | 1000 hours | Video signal strength check | Video signal analyzer |
| Insulation Test | 2000 hours | >100 MΩ at 500V DC | Insulation tester |
