| Parameter | Specification |
|---|---|
| COGENG Part Number | SV-VOL-11418522 |
| Replaces OEM Number | VOE11418522 |
| Valve Type | Hydraulic Solenoid Valve |
| Voltage Rating | 24V DC (OEM Standard) |
| Maximum Operating Pressure | 350 Bar (5,075 PSI) |
| Temperature Range | -40°C to +120°C (-40°F to +248°F) |
| Body Material | Carbon Steel with Anti-Corrosion Coating |
| Seal Material | Hydrogenated Nitrile (HNBR) |
| Electrical Connection | OEM-Compatible Weatherproof Connector |
| Fluid Compatibility | Mineral-based Hydraulic Oils (ISO VG 46) |
| Quality Certification | ISO 9001:2015 |
| NO | Number | Name | Qty |
| 1 | VOE17210349 | Oil distributor | 1 |
| 2 | VOE17211621 | Oil distributor | 2 |
| 3 | VOE17211650 | Oil distributor | 1 |
| 4 | VOE17211778 | Oil distributor | 1 |
| 5 | VOE11418522 | Solenoid Valve | 7 |
| 6 | VOE17214580 | Tube | 1 |
| 7 | VOE17214762 | Tube | 1 |
| 8 | VOE17424666 | Tube | 1 |
| 9 | VOE17214447 | Tube | 1 |
| 10 | VOE13933868 | Elbow nipple | 4 |
| VOE990738 | •O-ring | 4 | |
| VOE993321 | •O-ring | 4 | |
| 11 | VOE936607 | Nipple | 1 |
| VOE990738 | •O-ring | 2 | |
| VOE993321 | •O-ring | 1 | |
| 12 | VOE969404 | Six point socket screw | 14 |
| 13 | VOE976047 | O-ring | 5 |
| 14 | VOE984653 | Plug | 7 |
| 15 | VOE11037587 | Shim | REQ |
| VOE11037588 | Shim | REQ | |
| VOE11037589 | Shim | REQ | |
| 16 | VOE13946752 | Screw | 25 |
| 17 | VOE11419202 | Spacer washer | 1 |
| 18 | VOE11419377 | Spacer washer | 1 |
Always depressurize hydraulic system before installation
Use proper torque specifications during installation (15-20 Nm)
Verify electrical connection integrity before operation
Recommended hydraulic fluid flush during replacement
System diagnostic reset recommended after installation
Warranty: 24-month limited warranty
Support: Global technical support network
Availability: Ready for shipment worldwide
Q: What Volvo models use the VOE11418522 solenoid valve?
A: The COGENG solenoid valve is a direct replacement for Volvo OEM part number VOE11418522, designed for use in Volvo hydraulic systems across various construction equipment models where this solenoid valve is specified. Common applications include hydraulic control circuits on Volvo excavators, wheel loaders, and other heavy machinery. Always verify this part number against your machine's parts manual or the original solenoid valve's identification label to confirm exact compatibility before ordering.
Q: What are the symptoms of a failing solenoid valve on a Volvo hydraulic system?
A: Common symptoms include the controlled hydraulic function failing to operate or operating intermittently, slow or delayed response when the function is activated, the solenoid clicking but no hydraulic movement, the solenoid coil overheating, blown fuses related to the solenoid circuit, or the machine being restricted to a single operating mode. A faulty solenoid valve can also trigger diagnostic trouble codes within the Volvo machine control system.
Q: Is this solenoid valve a direct plug-and-play replacement?
A: Yes, the COGENG VOE11418522 solenoid valve is manufactured to exact OEM specifications for mounting dimensions, hydraulic port configuration, electrical connector type, voltage rating, coil resistance, and valve spool stroke. It is a direct plug-and-play replacement requiring no modifications when installed on compatible Volvo equipment.
Q: What voltage does this solenoid valve operate on?
A: This solenoid valve is designed to operate on the standard voltage specified by Volvo for the VOE11418522 part number, typically 24V DC for most Volvo construction equipment. Always verify your machine's system voltage before installation to ensure proper solenoid operation and to prevent coil damage.
